Vision Mamba on AMD GPU with ROCm#
State Space Models (SSMs), such as Mamba, have emerged as a potential alternative to Transformer models. Vision backbones using only SSMs have yielded promising results. For more information about SSMs and Mamba’s performance on AMD hardware, see Mamba on AMD GPUs with ROCm. This blog explores Vision Mamba (Vim), an innovative and efficient backbone for vision tasks and evaluate its performance on AMD GPUs with ROCm. We’ll start with a brief introduction to Vision Mamba, followed by a step-by-step guide on training and running inference with Vision Mamba on AMD GPUs using ROCm.
Vision Mamba#
Vision Mamba (Vim) is inspired by the Mamba in language modeling and it extends its principles to vision tasks. However, due to the inherent differences between language and vision tasks, directly applying Mamba to vision tasks is ineffective. This is because Mamba’s unidirectional modeling, suited for sequential data, lacks positional awareness crucial for vision tasks. To overcome this, Vim introduces a bidirectional selective state space model (SSM) for global visual context modeling and incorporates position embeddings for location-aware visual recognition.
Vim splits the input image into patches that are linearly projected into tokens. These patches are passed as a token sequence to the Vim block, which normalizes the token sequence and linearly projects it into x and z. The x sequence is processed from both forward and backward directions. The outputs from these backwards and forwards passes are gated by z and combined to produce the final output token sequence. Position embeddings provide spatial awareness, making Vim more robust for dense prediction tasks. For more information about Vim, see Vision Mamba: Efficient Visual Representation Learning with Bidirectional State Space Model.
Image source: Vision Mamba paper
Preparation and Setup#
The source code for Vim can be found in the Vision Mamba repo. The causal-conv1d and mamba-1p1p1 folders contain the CUDA source code which adds hardware-aware optimization for bidirectional Mamba. To run this code on ROCm, the CUDA source code needs to be translated to HIP C++. HIP is a C++ Runtime API and Kernel Language that allows developers to create portable applications for AMD and NVIDIA GPUs using the same source code. PyTorch uses a tool called Hipify_torch to translate source code from CUDA to HIP, making custom kernels that can run on ROCm. Translation is done internally within PyTorch when building the CUDA extension, ensuring a seamless experience when using custom kernels on ROCm. For more information on HIPIFY, see the HIPIFY documentation.
For comprehensive support details about the setup, please refer to the ROCm documentation. This blog was created using the following setup.
Hardware & OS:
Ubuntu 22.04.3 LTS
Software:
For this blog, we used the rocm/pytorch:rocm6.2_ubuntu20.04_py3.9_pytorch_release_2.1.2 docker image on a Linux machine equipped with MI210 GPUs and the AMD GPU driver version 6.7.0.
Getting Started#
Use the rocm/pytorch:rocm6.2_ubuntu20.04_py3.9_pytorch_release_2.1.2 Docker image and build Vision Mamba in the container.
docker pull rocm/pytorch:rocm6.2_ubuntu20.04_py3.9_pytorch_release_2.1.2
docker run -it --name vision_mamba --rm --ipc=host \
--device=/dev/kfd --device=/dev/dri/ \
--group-add=video --shm-size 8G \
rocm/pytorch:rocm6.2_ubuntu20.04_py3.9_pytorch_release_2.1.2
Build and install Vision Mamba on AMD GPU with ROCm.
git clone https://github.com/hustvl/Vim
cd Vim
pip install -r vim/vim_requirements.txt
# Install hipified packages required by Vision Mamba
pip install -e ./causal-conv1d
pip install -e ./mamba-1p1p1
There are three versions of the model for Vim:
Model |
#param. |
Top-1 Acc. |
Top-5 Acc. |
|---|---|---|---|
7M |
76.1 |
93.0 |
|
7M |
78.3 |
94.2 |
|
26M |
80.5 |
95.1 |
|
26M |
81.6 |
95.4 |
|
98M |
81.9 |
95.8 |
This blog uses Vim-small+ in the following test.
Note + means the model has been fine-tuned at finer granularity with short schedule. Please use the following command to download the weights for Vim-small.
wget https://huggingface.co/hustvl/Vim-small-midclstok/resolve/main/vim_s_midclstok_ft_81p6acc.pth
After completing these steps, you will obtain a weight file for Vim-small (e.g., vim_s_midclstok_ft_81p6acc.pth).
Note: If you only need to do inference, then you can skip the following dataset downloading. The dataset is only required for training and accuracy testing.
Use the ImageNet dataset for training and testing. ImageNet is a popular benchmark for vision models. Use the following command to download it. Depending on your network speed, this process may take several hours.
mkdir image_dataset
cd image_dataset
wget https://image-net.org/data/ILSVRC/2012/ILSVRC2012_img_val.tar
wget https://image-net.org/data/ILSVRC/2012/ILSVRC2012_img_train.tar
mkdir train && mv ILSVRC2012_img_train.tar train/ && cd train
tar -xvf ILSVRC2012_img_train.tar && rm -f ILSVRC2012_img_train.tar
# Extract each .tar file into its own directory
find . -name "*.tar" | while read -r NAME; do
mkdir -p "${NAME%.tar}"
tar -xvf "${NAME}" -C "${NAME%.tar}" && rm -f "${NAME}"
done
rm train/n04266014/n04266014_10835.JPEG
cd ..
mkdir val && mv ILSVRC2012_img_val.tar val/ && cd val && tar -xvf ILSVRC2012_img_val.tar
wget -qO- https://raw.githubusercontent.com/soumith/imagenetloader.torch/master/valprep.sh | bash
Everything is now set up for accuracy testing, training, and inference with Vision Mamba on AMD GPUs using ROCm.
Accuracy Test#
In this section, we will evaluate the performance of Vision Mamba (small) on the ImageNet dataset. The accuracy test will help verify that the model is functioning correctly on AMD GPUs with ROCm.
cd Vim
python ./vim/main.py --eval --resume ./vim_s_midclstok_ft_81p6acc.pth \
--model vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2 \
--data-path ./image_dataset
The output should be similar to the one below. The full training log can be found in the ROCm blogs repository.
Namespace(batch_size=64, epochs=300, bce_loss=False, unscale_lr=False, model='vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2', input_size=224, drop=0.0, drop_path=0.1, model_ema=True, model_ema_decay=0.99996, model_ema_force_cpu=False, opt='adamw', opt_eps=1e-08, opt_betas=None, clip_grad=None, momentum=0.9, weight_decay=0.05, sched='cosine', lr=0.0005, lr_noise=None, lr_noise_pct=0.67, lr_noise_std=1.0, warmup_lr=1e-06, min_lr=1e-05, decay_epochs=30, warmup_epochs=5, cooldown_epochs=10, patience_epochs=10, decay_rate=0.1, color_jitter=0.3, aa='rand-m9-mstd0.5-inc1', smoothing=0.1, train_interpolation='bicubic', repeated_aug=True, train_mode=True, ThreeAugment=False, src=False, reprob=0.25, remode='pixel', recount=1, resplit=False, mixup=0.8, cutmix=1.0, cutmix_minmax=None, mixup_prob=1.0, mixup_switch_prob=0.5, mixup_mode='batch', teacher_model='regnety_160', teacher_path='', distillation_type='none', distillation_alpha=0.5, distillation_tau=1.0, cosub=False, finetune='', attn_only=False, data_path='./image1k2012/tarfile', data_set='IMNET', inat_category='name', output_dir='', device='cuda', seed=0, resume='./vim_s_midclstok_ft_81p6acc.pth', start_epoch=0, eval=True, eval_crop_ratio=0.875, dist_eval=False, num_workers=10, pin_mem=True, distributed=False, world_size=1, dist_url='env://', if_amp=True, if_continue_inf=False, if_nan2num=False, if_random_cls_token_position=False, if_random_token_rank=False, local_rank=0, gpu=None)
Creating model: vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2
number of params: 26001256
Test: [ 0/27] eta: 0:22:19 loss: 0.5674 (0.5674) acc1: 88.4896 (88.4896) acc5: 98.3333 (98.3333) time: 49.6074 data: 18.4177 max mem: 49186
Test: [10/27] eta: 0:03:52 loss: 0.7132 (0.6941) acc1: 83.8021 (85.2510) acc5: 97.3438 (97.2064) time: 13.6715 data: 1.6747 max mem: 49193
Test: [20/27] eta: 0:01:23 loss: 0.8571 (0.8317) acc1: 81.5625 (82.3289) acc5: 95.4167 (95.6324) time: 10.0834 data: 0.0003 max mem: 49193
Test: [26/27] eta: 0:00:11 loss: 0.9202 (0.8809) acc1: 80.2604 (81.5600) acc5: 94.2188 (95.4420) time: 9.6160 data: 0.0002 max mem: 49193
Test: Total time: 0:05:02 (11.2071 s / it)
* Acc@1 81.560 Acc@5 95.442 loss 0.881
Accuracy of the network on the 50000 test images: 81.6%
This result closely matches the results reported by the author, confirming that the ROCm-enabled setup and the modifications made using Hipify_torch work as expected.
Vision Mamba Distributed Data Parallel Training on AMD GPU with ROCm#
Training can take a very long time (i.e., days) if you use a small GPU. To speed up the process, DistributedDataParallel is used to run multiple processes across all 8 AMD Instinct MI210 GPUs. Depending on your GPU type and memory capacity, you need to adjust the batch_size and num_workers values—either increasing them to fully maximize resource utilization or reducing them to prevent out-of-memory (OOM) issues. Based on our tests, training takes approximately 5 hours on 8 AMD Instinct MI210 GPUs and around 2 hours on 8 AMD Instinct MI300X GPUs. Please note, these times are provided for reference only and are not optimized for the fastest training speed. Actual performance may vary depending on your specific setup.
cd Vim
torchrun --nnodes 1 --nproc_per_node 8 ./vim/main.py \
--model vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2 \
--batch-size 128 --lr 5e-6 --min-lr 1e-5 --warmup-lr 1e-5 --drop-path 0.0 --weight-decay 1e-8 --num_workers 8 \
--data-path ./image_dataset --output_dir ./output/vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2\
--epochs 1 --finetune ./vim_s_midclstok_ft_81p6acc.pth --no_amp
Outputs:
```text
[2024-09-09 04:43:53,537] torch.distributed.run: [WARNING]
[2024-09-09 04:43:53,537] torch.distributed.run: [WARNING] *****************************************
[2024-09-09 04:43:53,537] torch.distributed.run: [WARNING] Setting OMP_NUM_THREADS environment variable for each process to be 1 in default, to avoid your system being overloaded, please further tune the variable for optimal performance in your application as needed.
[2024-09-09 04:43:53,537] torch.distributed.run: [WARNING] *****************************************
Namespace(batch_size=128, epochs=1, bce_loss=False, unscale_lr=False, model='vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2', input_size=224, drop=0.0, drop_path=0.0, model_ema=True, model_ema_decay=0.99996, model_ema_force_cpu=False, opt='adamw', opt_eps=1e-08, opt_betas=None, clip_grad=None, momentum=0.9, weight_decay=1e-08, sched='cosine', lr=5e-06, lr_noise=None, lr_noise_pct=0.67, lr_noise_std=1.0, warmup_lr=1e-05, min_lr=1e-05, decay_epochs=30, warmup_epochs=5, cooldown_epochs=10, patience_epochs=10, decay_rate=0.1, color_jitter=0.3, aa='rand-m9-mstd0.5-inc1', smoothing=0.1, train_interpolation='bicubic', repeated_aug=True, train_mode=True, ThreeAugment=False, src=False, reprob=0.25, remode='pixel', recount=1, resplit=False, mixup=0.8, cutmix=1.0, cutmix_minmax=None, mixup_prob=1.0, mixup_switch_prob=0.5, mixup_mode='batch', teacher_model='regnety_160', teacher_path='', distillation_type='none', distillation_alpha=0.5, distillation_tau=1.0, cosub=False, finetune='./vim_s_midclstok_ft_81p6acc.pth', attn_only=False, data_path='./image_dataset', data_set='IMNET', inat_category='name', output_dir='./output/vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2', device='cuda', seed=0, resume='', start_epoch=0, eval=False, eval_crop_ratio=0.875, dist_eval=False, num_workers=8, pin_mem=True, distributed=True, world_size=8, dist_url='env://', if_amp=False, if_continue_inf=False, if_nan2num=False, if_random_cls_token_position=False, if_random_token_rank=False, local_rank=0, gpu=0, rank=0, dist_backend='nccl')
Creating model: vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2
number of params: 26001256
Start training for 1 epochs
Epoch: [0] [ 0/1251] eta: 4:05:42 lr: 0.000010 loss: 2.8620 (2.8620) time: 11.7846 data: 1.4589 max mem: 58000
Epoch: [0] [ 10/1251] eta: 1:21:45 lr: 0.000010 loss: 2.8620 (2.7414) time: 3.9532 data: 0.1329 max mem: 58204
Epoch: [0] [ 20/1251] eta: 1:13:30 lr: 0.000010 loss: 2.7010 (2.7007) time: 3.1725 data: 0.0003 max mem: 58204
Epoch: [0] [ 30/1251] eta: 1:10:40 lr: 0.000010 loss: 2.7748 (2.7117) time: 3.2089 data: 0.0003 max mem: 58205
Epoch: [0] [ 40/1251] eta: 1:08:46 lr: 0.000010 loss: 2.7195 (2.6884) time: 3.2240 data: 0.0003 max mem: 58205
Epoch: [0] [ 50/1251] eta: 1:07:18 lr: 0.000010 loss: 2.6703 (2.6825) time: 3.1924 data: 0.0003 max mem: 58206
...
Epoch: [0] [1210/1251] eta: 0:02:13 lr: 0.000010 loss: 2.6030 (2.5552) time: 3.1808 data: 0.0004 max mem: 58206
Epoch: [0] [1220/1251] eta: 0:01:41 lr: 0.000010 loss: 2.5304 (2.5541) time: 3.1812 data: 0.0004 max mem: 58206
Epoch: [0] [1230/1251] eta: 0:01:08 lr: 0.000010 loss: 2.5217 (2.5542) time: 3.1813 data: 0.0004 max mem: 58206
Epoch: [0] [1240/1251] eta: 0:00:35 lr: 0.000010 loss: 2.6710 (2.5543) time: 3.1810 data: 0.0006 max mem: 58206
Epoch: [0] [1250/1251] eta: 0:00:03 lr: 0.000010 loss: 2.5232 (2.5541) time: 3.1798 data: 0.0005 max mem: 58206
Epoch: [0] Total time: 1:08:01 (3.2629 s / it)
Averaged stats: lr: 0.000010 loss: 2.5232 (2.5604)
Test: [ 0/14] eta: 1:01:08 loss: 0.7193 (0.7193) acc1: 83.8802 (83.8802) acc5: 97.0313 (97.0313) time: 262.0067 data: 77.2542 max mem: 99122
Test: [10/14] eta: 0:02:53 loss: 0.8385 (0.8442) acc1: 82.8906 (81.9058) acc5: 95.1042 (95.4380) time: 43.4364 data: 7.0233 max mem: 99137
Test: [13/14] eta: 0:00:37 loss: 0.8385 (0.9020) acc1: 81.4583 (81.5280) acc5: 95.0000 (95.3680) time: 37.1473 data: 5.5183 max mem: 99137
Test: Total time: 0:08:40 (37.1782 s / it)
* Acc@1 81.469 Acc@5 95.298 loss 0.906
Accuracy of the network on the 50000 test images: 81.5%
Max accuracy: 81.47%
Training time 1:16:43
According to the paper, the vim_s_midclstok_ft_81p6acc.pth checkpoint was fine-tuned on the ImageNet dataset. The goal of the training done in the context of this blog was not to surpass the existing results through further fine-tuning with different settings, but to verify that Distributed Data Parallel (DDP) training on AMD GPUs with ROCm functions correctly with our modifications using ‘Hipify_torch’.
After training is done, the checkpoints will be found in ./output/vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2.
Vision Mamba Inference on AMD GPU with ROCm#
Vim can be used for inference tasks such as image classification, segmentation, and detection. The model generated in the previous steps will be used on an image classification task to demonstrate Vim’s inference capabilities on AMD GPUs with ROCm, we use the model generated in the previous step for an image classification task. The images (cab.png and cat.jpeg) and file (imagenet_class_index.json) used during the test are available in the ROCm blogs repository.
pip install rope
import torch
from PIL import Image
from torchvision import transforms
from timm.data.constants import IMAGENET_DEFAULT_MEAN, IMAGENET_DEFAULT_STD
from vim.models_mamba import VisionMamba
from vim.models_mamba import (
vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2)
# Create Vim model and load the weights
model = vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2()
sd = torch.load("./output/vim_small_patch16_stride8_224_bimambav2_final_pool_mean_abs_pos_embed_with_midclstok_div2/best_checkpoint.pth")
model.load_state_dict(sd["model"])
model.eval()
model.to("cuda")
def inference(model, image):
## preprocess image
test_image = Image.open(image).convert('RGB')
test_image.show()
test_image = test_image.resize((224, 224))
image_as_tensor = transforms.ToTensor()(test_image)
normalized_tensor = transforms.Normalize(
IMAGENET_DEFAULT_MEAN, IMAGENET_DEFAULT_STD
)(image_as_tensor)
## inference with vision mamba
x = normalized_tensor.unsqueeze(0).cuda()
pred = model(x)
## decode the output and print the class
import json
f = open('./src/imagenet_class_index.json')
class_idx = json.load(f)
idx2label = [class_idx[str(k)][1] for k in range(len(class_idx))]
print(f"label: class - {pred.argmax()}:{idx2label[pred.argmax()]}")
inference(model,"./image/cab.png")
inference(model,"./image/cat.jpeg")
Outputs:
label: class - 468:cab
label: class - 282:tiger_cat
The output looks correct! The model correctly identifies the images. This demonstrates that Vision Mamba can be used for inference tasks on AMD GPUs with ROCm.
Summary#
In this blog, we explored Vision Mamba on AMD GPUs with ROCm, showcasing its capabilities and performance for vision tasks. The hipified Vision Mamba effectively leverages AMD hardware for both training and inference, offering a robust alternative to traditional models. We encourage readers to experiment with Vision Mamba in their computer vision applications using ROCm on AMD GPUs.
