Understanding Peak, Max-Achievable & Delivered FLOPs, Part 1#
The purpose of this blog post is to provide information on the differences between Peak FLOPs and Max-achievable FLOPs. After reading, users will know how AMD measures maximum delivered performance, and how AMD recommends measured device performance is used.
Historically, terms such as peak FLOPs, max achievable FLOPs, and delivered FLOPs have been used interchangeably, creating confusion and incorrect comparisons. While all three concepts are useful, it is important that they be used in a consistent and well-defined manner.
Peak FLOPs#
Peak FLOPs (or Peak Theoretical FLOPs) are a well-established metric used in specification sheets to describe the maximum theoretical performance capabilities of CPU and GPU devices. FLOPs are the floating-point operations per second. The formula is simple and easy to understand:
Boost_Clock_Frequency[1]: The maximum clock rate achievable by the device. The Boost clock (or Max boost) is not a theoretical metric - it can be achieved by the device (typically in a lightly loaded scenario such as a single core or a low-power workload phase). Boost clock is determined by hardware design characteristics such as the transistor gates/clock, the power consumption, and the process technology.
Number_Cores : For CPUs this is the number of processing cores, and for GPUs the number of Compute Units (aka Streaming Multiprocessors).
OPS/Core/Cycle : The number of floating point operations per core that can be processed in a single cycle. Peak FLOPs is traditionally focused on matrix multiplication (aka “GEMM”) and devices will have different rates depending on the data type (with faster rates for ML-focused data types such as F16 or FP8). For processors with a fused multiply-accumulate (FMA) instruction, both the multiply and the accumulate count as an “op” for the purposes of this metric.
Table 1 compares the Peak half precision (BF16) FLOPs of a few current-generation CPU and GPU products:
Product |
Max Boost Clock Freq. |
Number of Cores |
OPS/Core/Cycle |
BF16 Peak TFLOPs (without sparsity) |
|---|---|---|---|---|
AMD EPYC 9965 |
3700 Mhz |
192 (CPU Cores) |
128 |
91 |
AMD Instinct MI325XMI325-008 |
2100 Mhz |
304 (Compute Units) |
2048 |
1307 |
NVIDIA H200MI325-008 |
1803 Mhz |
134 (Compute Units) |
4096 |
989 |
Table 1: Example Peak BF16 FLOPs (without sparsity) calculations for modern CPUs and GPUs.
The AMD Instinct MI325X has a higher boost clock and more compute units than the Nvidia H200, which enables the MI325X to drive high Peak FLOPs. The AMD CPU has a high Boost clock (useful for single-thread workloads) and a high number of cores, with a modest vectorized floating point investment via the AVX512 ISA.
Both GPUs in the table have dedicated tensor core arrays which deliver very high floating-point rates for ML data types – more than 10X higher “Ops_Per_Core” as compared to the EPYC 9965 CPU.
The Peak FLOPs provide a consistent cross-vendor comparison point based on pure hardware metrics and can be computed without needing to run a benchmark on the target device.
Additionally, the Boost clock is an important component of application performance - the processor can boost to the highest clock during lightly loaded situations and improve latency through critical-path execution regions. In machine learning applications, this can improve latency of small kernels, element-wise operations, and kernel sections like address computations and setup code.
Max-Achievable FLOPs#
The “Max-Achievable FLOPs” (MAF) are the maximum achievable FLOPs under realistic workload situations (e.g. normalized data initialization, stable thermal conditions, cold caches) using a device-specific optimal matrix size chosen to maximize architectural efficiency. MAF has a specific definition and with care can be measured on any target device – we’ll share our measurement methodology later in part two of this discussion.
Understanding MAF is crucial since it removes the opaque hardware components (e.g., the actual processing frequency) from the target metric and allows developers to focus on factors that they can control. For example, developers optimizing compute kernels (e,g. flash attention), writing library routines (e.g. AMD hipBLASlt), or developing compilers (e.g. Triton or MLIR) can use MAF to understand if the performance they measure is close to the achievable hardware capabilities. Essentially, MAF helps optimizers to know when they are done optimizing.
One specific use case for MAF is in refactoring the classic “MFU” metric:
MFU is common metric used in model optimization to determine the current software optimization level. Model optimizers often pursue model-level optimizations (fusing kernels, overlapping communication, tuning hyper-parameters, adjusting batch, etc.) until the model performance approaches the MFU. Traditionally MFU has been computed using Peak FLOPs in the denominator, but AMD recommends replacing this with MAF as this is a more achievable target.
History of Peak and Max-Achievable FLOPs#
Peak FLOPs is a long-standing industry standard that has been used for decades to compare CPU, GPU, and HPC products. Historically, the MAF tracked the peak FLOPs relatively closely - often within a few percent - and the two terms could be used nearly interchangeably.
Figure 1: Peak and MAF FLOPs Diverging over Time[2]
However, with the rise of ML workloads, the silicon area and power invested in matrix floating point multiplication has increased significantly - evolving from packed vector FMAs to powerful tensorcore arrays. For example, a modern GPU core now has more than 10X the floating-point compared to earlier-generation GPUs.
Product |
OPS/Core/Cycle |
Ratio |
Architecture |
|---|---|---|---|
P100 (Pascal) |
256 |
1.0 X |
Vector FMA |
V100 (Volta) |
1024 |
4.0 X |
Tensor Core |
A100 (Ampere) |
2048 |
8.0 X |
Tensor Core |
H100 (Hopper) |
4096 |
16.0 X |
Tensor Core |
Table 2: Increasing silicon investment in matrix-multiplication over product generations.
This dedicated silicon consumes a significant amount of power, and the optimal operating point runs a wider set of logic at a clock frequency which is lower than the Boost clock frequency. Modern GPUs have sophisticated power management algorithms which detect the power consumption of the device - raising the clock rate to the Boost clock when possible and lowering it in the dense compute phases. These transitions are handled automatically by the hardware and can occur frequently (i.e. in micro-seconds) - even during the execution of a GPU kernel.
In simpler times, the ratio of MAF:Peak could be used as a measure of software optimization efficiency. However, on modern CPUs and GPUs, with their specialized matrix hardware and diverse workload requirements requiring sophisticated power and frequency management, this is no longer true – we estimate based on preliminary testing that the gap is at 44-70% as shown on the right side of Figure 1. Both high Peak FLOPs (with associated high Boost frequency) and high Max-achievable FLOPs are desirable features for a modern processor.
Delivered FLOPs#
You may see the term “Delivered FLOPs” – sometimes this can refer to the MAF, or sometimes it refers to the GEMM performance inside the application, etc. Recall MAF is a well-defined and measurable number: it is the maximum achievable FLOPs when using an optimally chosen matrix size under a specific environment. In an actual application, with less optimal sizes and less controlled conditions, performance results may differ from MAF. Some reasons the FLOPs seen during a GEMM inside an application may differ from MAF include:
Memory-bound kernels – kernels which are skinny in at least one dimension will be bounded by the memory bandwidth and not the compute FLOPs.
Small K dimension – the K value determines the amount of time spent in the inner loop of the GEMM. If K is large, it amortizes the startup effects, and the performance approaches the MAF. If K is small – these startup effects become significant. Each GPU kernel incurs a startup delay of a few micro-seconds – the hardware has to set up the state for the new kernel, fetch the kernel arguments, compute addresses, and load the first pieces of data from memory. Additionally, some or all of the final epilogue and store to memory is exposed and cannot be overlapped.
Unused Compute Units – classic GPU matrix multiplication algorithms divide the output space into a number of tiles, and each tile is assigned to a compute unit. If the number of tiles does not divide evenly among the CUs, the GEMM will experience a tail phase in which only a subset of the machine is used. In the near future, AMD libraries plan to include a “STREAM-K” algorithm that provides better load-balancing for these GEMM shapes.
Environmental effects – ambient temperatures, part-to-part variability, quality of the cooling solution.
Data initialization – zeros or constant values consume less power than numbers with variation in exponents and toggle rates.
Power management – the power management may not run the GEMM at its optimal frequency.
Software optimization – there are a wide variety of different GEMM optimizations techniques. The MAF focuses on core compute kernel performance – real sizes may require additional optimization attention in other parts of the kernel, or different algorithmic techniques.
Selection heuristics - GEMMs have a number of different possible algorithms – different tile sizes, unroll factors, load strategies, split-k, stream-k, etc. The hipBLASLt library is responsible for mapping each new set of M, N, K and other parameters to the best available solution in the library. Choosing the wrong solution may provide lower performance. In some cases, this performance can be recovered by applying a user-driven auto-tuning flow that searches and find the optimal algorithm from the “menu” provided by the library.
Summary and Next Steps#
Hopefully this article helps to understand the history of FLOPs measurement, and why both peak and MAF are important metrics as we move forward into the age of ML-optimized silicon. For most cases, AMD recommends using MAF as a target for kernel and model optimization - as this metric gives a more realistic target for the optimization knobs that are under the developers control.
Max-Achievable FLOPs are important but just one component of the overall workload performance. Other key factors that influence performance include memory bandwidth, communication latency and bandwidth, and memory capacity. Machine learning workloads exhibit different sensitivities to these factors:
The “prefill” or “prompt” phase of generative AI inference tends to have large matrices and be sensitive to MAF performance. The summarization use case (e.g. summarize a long document or email) is dominated by the prefill phase - by definition the summarization process boils down a large number of input tokens to a small number of output tokens.
On the other hand “decode” or token-generation phase is dominated by an auto-regressive algorithm which is sensitive to memory bandwidth. The chat use case - where a user provides a relatively short prompt and expects a large number of output tokens - would have a short “prefill” phase followed by a relatively large “token” phase. Some recent reasoning models generate an even larger number of “thinking” tokens which further emphasize the importance of this phase.
Parallelizing a workload across multiple GPUs will sensitize the communication performance, but in some cases a GPU with high memory capacity can fit the model and KV cache states in a single GPU or single node and substantially reduce or even eliminate the communication. Capacity can also provide spectacular throughput gains by enabling higher batch sizes.
For more information on workload performance, see the recent blogs on Best practices for competitive inference optimization on AMD Instinct™ MI300X and Enhancing AI Training with AMD ROCm Software.
