DGL in the Real World: Running GNNs on Real Use Cases#
In our previous blog post, we introduced the Deep Graph Library (DGL) and highlighted how its support on the AMD ROCm platform unlocks scalable, performant graph neural networks (GNNs) on AMD GPUs. That post focused on the why — the growing relevance of graph workloads and what it means to bring that capability to AMD’s accelerated computing ecosystem.
In this follow-up, we shift to the how. We walk through four advanced GNN workloads — from heterogeneous e-commerce graphs to neuroscience applications — that we successfully ran using our DGL implementation.
Our goal is to validate:
Functionality — Does the model run end-to-end on ROCm without major changes?
Compatibility — Does it integrate cleanly with ROCm?
Ease of use — How much extra setup is needed?
For each use case, we’ll cover:
The task and dataset
How DGL was used
ROCm porting experience
They’re real-world examples showing what already works — so developers can hit the ground running with GNNs on AMD GPUs.
The Docker images, installation instructions, and compatibility matrix are all available here:
Use Case 1: GNN-FiLM-Graph Neural Networks with Feature-wise Linear Modulation#
GNN-FiLM introduces feature-wise linear modulation into GNNs by using the target node’s representation to transform all incoming messages. This enables more context-aware message passing and, in experiments across multiple benchmark tasks, delivers competitive results—outperforming strong baselines on molecular graph regression.
Task/Dataset: We used DGL’s built-in PPIDataset (24 graphs, ~2.3K nodes each, 50 features, 121 labels) for inductive node classification.
How DGL helped:
Loaded graphs directly with dgl.data.PPIDataset.
Batched with dgl.batch().
Used dgl.function for efficient message passing.
ROCm experience: The model ran out-of-the-box — no tweaks to data loading, batching, or message passing were needed.
To run the GNN-FiLM example
Use any of the containers mentioned on this DockerHub page
In the GNNFiLM folder, run
python main.py --gpu ${your_device_id_here}
Use Case 2: ARGO-An Auto-Tuning Runtime System for Scalable GNN Training on Multi-Core Processors#
While our work usually focuses on GPUs, this experiment showed DGL’s flexibility beyond accelerators.
Task: ARGO speeds up GNN training on multi-core CPUs by up to 5X via smart multiprocessing, core binding, and auto-tuning — all layered under DGL without changing the model code.
How DGL helped:
DGL remains the core graph processing library that provides the APIs, graph data structures, and GNN model implementations you already know and use. ARGO doesn’t replace DGL; instead, it acts as a performance-enhancing runtime layer underneath it.
Specifically, ARGO integrates with DGL by:
Intercepting the GNN training workflow to manage how computation tasks are distributed across multiple CPU cores.
Applying multi-processing and core-binding strategies to efficiently schedule DGL’s graph operations, maximizing CPU and memory bandwidth usage.
Using its auto-tuner to automatically discover the best way to configure these runtime parameters, adapting to your specific hardware, model, and dataset.
In essence, ARGO acts as a smart “orchestrator” that boosts DGL’s ability to run efficiently on multi-core CPUs, without requiring changes to your existing DGL codebase. You just plug ARGO in, and it transparently accelerates your GNN training by optimizing resource utilization under the hood.
ROCm experience: Even though this was CPU-based, it proved that DGL’s API and ecosystem can scale across very different hardware targets.
To run the ARGO example
Use any of the containers mentioned on this DockerHub page
ARGO utilizes the scikit-optimize library for auto-tuning. Please install the following dependencies to run ARGO:
pip install scikit-optimize\>=0.9 pip install ogb
In the ARGO folder run
python main.py --dataset ogbn-products --sampler shadow --model sage
Use Case 3: Representation Learning for Attributed Multiplex Heterogeneous Network - GATNE#
One of the most powerful use cases of DGL is learning expressive, scalable representations from large, complex real-world networks. Many such networks — like those found in e-commerce, social media, and content platforms — are Attributed Multiplex Heterogeneous Networks, where nodes and edges come in multiple types, and each node is rich with features. Traditional graph embedding methods struggle with scalability and heterogeneity.
Task: We implemented the GATNE model, which supports both transductive and inductive learning. At Alibaba, GATNE improved recommendation system F1 scores by 5.99–28.23% over DeepWalk.
Figure 1: How GATNE powers smarter recommendations
In Figure 1 above you can see how on the left, each user and item has rich attributes (age, location, price, brand) and multiple types of connections (click, add-to-preference, add-to-cart, purchase). The middle shows three ways to represent such graphs — from simpler homogeneous (HON) to full attributed multiplex heterogeneous (AMHEN). On the right, GATNE-I’s boost in F1 score (+28.23%) over DeepWalk shows why richer graph modeling pays off in real-world systems like Alibaba’s product recommendations.
How DGL helped:
Built complex graphs with dgl.heterograph() for multiple node/edge types.
Performed mini-batch training via sample_neighbors() and to_block().
Used node ID mappings (block.srcdata[dgl.NID]) to fetch/update embeddings.
Generated skip-gram context nodes with random_walk().
ROCm experience:
After porting DGL from CUDA to ROCm, the entire GATNE pipeline ran without a single code change. Graph construction, sampling, and random walks all worked seamlessly.
To run the GATNE example
Use any of the containers mentioned on this DockerHub page
Install the following
pip install tqdm numpy scikit-learn networkx gensim requests
Download the dataset of your choice
example: https://s3.us-west-2.amazonaws.com/dgl-data/dataset/recsys/GATNE/example.zip
amazon: https://s3.us-west-2.amazonaws.com/dgl-data/dataset/recsys/GATNE/amazon.zip
youtube: https://s3.us-west-2.amazonaws.com/dgl-data/dataset/recsys/GATNE/youtube.zip
twitter: https://s3.us-west-2.amazonaws.com/dgl-data/dataset/recsys/GATNE/twitter.zip
Unzip the datasets
Run the amazon dataset in the GATNE-T
python src/main.py --input data/amazon --eval-type 1 --gpu 0
Use Case 4: EEG-GCNN-Augmenting Electroencephalogram-based Neurological Disease Diagnosis using a Domain-guided Graph Convolutional Neural Network#
EEG-GCNN is a groundbreaking graph convolutional neural network approach designed to boost the accuracy of neurological disease diagnosis from scalp EEGs. While traditional expert visual analysis catches abnormalities only about 50% of the time, this model captures both spatial and functional connections between electrodes to spot cases missed by experts.
How DGL helped:
Built complete 8-node electrode graphs with features and weighted edges.
Applied GraphConv layers and pooling for classification.
Figure 2. From brainwaves to diagnosis
In Figure 2 above you can see how EEG-GCNN turns raw scalp EEG into graph data by splitting signals into 10-second windows, calculating brain activity correlations (PSD) between electrodes, and mapping these into a feature-rich electrode graph. The result is a model that can detect subtle patterns in neurological disorders that even experts often miss.
ROCm experience: Just like the other use cases we explored, EEG-GCNN ran seamlessly out of the box with our DGL port—no code changes needed to build graphs, apply GraphConv, or run pooling operations on EEG data.
To run the EEG-GCNN example
Use any of the containers mentioned on this DockerHub page
Download the following dataset and unzip it
wget <https://ndownloader.figshare.com/files/25518170>Copy the following files in the eeg-gcnn folder
figshare_upload/master_metadata_index.csv, figshare_upload/psd_features_data_X, figshare_upload/labels_y, figshare_upload/psd_shallow_eeg-gcnn/spec_coh_values.npy, and figshare_upload/psd_shallow_eeg-gcnn/standard_1010.tsv.txt
In the eeg-gcnn folder run
python main.pyThe default model used is shallow_EEGGraphConvNet.py. To use deep_EEGGraphConvNet.py, run
python main.py --model deep
Beyond These Four Models#
In addition to specific models and scenarios discussed above, it is also possible to utilize DGL for a wide variety of other use-cases. DGL can train graph neural network models that are industry standards such as the following,
Models such as GAT Graph Attention Networks, GCN Semi-Supervised Classification with Graph Convolutional Networks and GraphSage Inductive Representation Learning on Large Graphs are widely used in various real-world examples.
We have trained and tested these networks on the pubmed and cora datasets, however additional datasets and additional scenarios can also be incorporated.
Summary#
We validated that DGL models run end-to-end on ROCm with minimal changes, integrate cleanly with AMD GPUs, and require only simple setup—hitting all our functionality, compatibility, and ease-of-use goals. These are real-world GNN examples, not synthetic benchmarks, and they work out of the box, so developers can jump straight into experimentation on ROCm without wrestling with backend issues.
If you’re building GNN workloads with DGL, now’s the time to try them on AMD GPUs. Your existing code should just work on AMD Instinct GPUs without any customization — and you’ll gain access to scalable, high-performance execution across a growing range of models and datasets.
We’d love to hear about your use cases, contribute to your success stories, or even collaborate on expanding our example suite.
This is blog 2 of our 3-part DGL series. In the next and final post, we’ll take a hands-on look at how DGL powers drug discovery through graph-based learning—showing how these capabilities translate into breakthroughs in real-world scientific applications.
Acknowledgements#
The authors would also like to acknowledge the broader AMD team whose contributions were instrumental in enabling DGL: Mukhil Azhagan Mallaiyan Sathiaseelan, Anuya Welling, James Smith, Vicky Tsang, Tiffany Mintz, Pei Zhang, Debasis Mandal, Yao Liu, Phani Vaddadi, Vish Vadlamani, Ritesh Hiremath, Bhavesh Lad, Radha Srimanthula, Mohan Kumar Mithur, Phaneendr-kumar Lanka, Jayshree Soni, Amit Kumar, Leo Paoletti, Anisha Sankar, Ram Seenivasan, Aditya Bhattacharji, Marco Grond, Anshul Gupta, Saad Rahim
Additional Resources#
Explore the source code and read the original papers here -
GNN-FiLM: Graph Neural Networks with Feature-wise Linear Modulation Original Paper - GNN-FiLM: Graph Neural Networks with Feature-wise Linear Modulation
GitHub code - DGL Implementation of the GNN-FiLM Model
ARGO: An Auto-Tuning Runtime System for Scalable GNN Training on Multi-Core Processor Original Paper - ARGO: An Auto-Tuning Runtime System for Scalable GNN Training on Multi-Core Processor
GitHub code – DGL implementation of ARGO
Representation Learning for Attributed Multiplex Heterogeneous Network - GATNE Original Paper - Representation Learning for Attributed Multiplex Heterogeneous Network
GitHub code – DGL implementation of GATNE
EEG-GCNN: Augmenting Electroencephalogram-based Neurological Disease Diagnosis using a Domain-guided Graph Convolutional Neural Network Original Paper - EEG-GCNN: Augmenting Electroencephalogram-based Neurological Disease Diagnosis using a Domain-guided Graph Convolutional Neural Network
GitHub code – DGL Implementation of EEG-GCNN Paper
