GEMM Tuning within hipBLASLt - Part 1

GEMM Tuning within hipBLASLt - Part 1#

GEMM Tuning within hipBLASLt - Part 1
September 05, 2025 by YangWen Huang, Carson Liao.
3 min read. | 653 total words.
Software tools & optimizations
AI/ML, Developers
AI, Developers

When optimizing matrix operations on AMD GPUs using the ROCm platform, tuning specific problem sizes is essential for achieving maximum performance. The hipBLASLt library supports two official tuning mechanisms:

  • Offline Tuning Utility: This method uses tools like find_exact.py to generate optimized kernel solutions for specific GEMM problem sizes. These solutions are then merged back into the library source and require recompilation.

    • Pro: Developers retain control of tuned solutions and can rebuild them with every ROCm upgrade.

    • Con: Requires recompilation after each library update.

  • hipblaslt-bench offline tuning: This approach generates a runtime configuration file that overrides the default kernel selection without needing to recompile the library.

    • Pro: Easy deployment—no rebuild needed.

    • Con: Solution indices may change with each ROCm version, requiring re-tuning after upgrades.

In this post, we explore the offline Tuning Utility workflow using find_exact.py, which allows developers to generate and retain their own optimal GEMM solutions across builds. In the next post, we’ll introduce the hipblaslt-bench offline tuning which allows developers to tune their own optimal GEMM solutions without recompiling the entire library. The first method offers more fine-grained controls while the latter one offers an easy-to-use workflow.

What is find_exact.py?#

find_exact.py is a utility that leverages the hipBLASLt tuning engine to:

  • Search for the optimal solution (kernel) for specific GEMM problems.

  • Measure and report performance (execution time).

  • Output the solutions in logical YAML format to be merged back into the library source, requiring recompilation for deployment.

This is particularly valuable when your workload involves fixed matrix shapes—common in deep learning, graphics, or HPC workloads—where runtime tuning isn’t feasible or desirable.

Defining Problems in template.yaml#

The input to find_exact.py is a YAML configuration file that defines the tuning workflow and problem sizes. The latest format organizes tuning into two main steps:

  • Bench: benchmark and tune specified problem sizes.

  • CreateLogic / UpdateGrid: store the results in the logic YAML format suitable for integration with the hipBLASLt library.

Here is an example from the updated template.yaml:

# Can comment out Bench, CreateLogic, or UpdateGrid if you want to disable.
Bench:
  ProblemType:
    ComputeDataType: s
    ComputeInputDataType: s
    DataTypeA: s
    DataTypeB: s
    DataTypeC: s
    DataTypeD: s
    TransposeA: 0
    TransposeB: 0
    UseBias: False
  TestConfig:
    ColdIter: 20
    Iter: 100
    AlgoMethod: "all"
    RotatingBuffer: 512
  TuningParameters:
    # SplitK list control parameter example
    SplitK: [0, 4, 8]
  ProblemSizes:
  - [128, 128, 1, 128]
  - [128, 128, 1, 128]

# Create equality
CreateLogic: {}

# Update existing grid
UpdateGrid: {}

Key Sections Explained#

  • Bench: Defines the set of problem sizes to benchmark and tune. It includes:

    • ProblemType: Describes the data types, transpose flags, and bias usage for the GEMM operation.

    • TestConfig: Controls benchmarking behavior, such as iteration count and algorithm selection.

    • TuningParameters: Optional fine-tuning controls (e.g., SplitK values).

    • ProblemSizes: A list of problem size tuples in the form [M, N, Batch, K].

  • CreateLogic: When enabled, this step generates equality logic entries, where the exact problem size maps to a specific tuned solution. These are written into logic YAMLs, which can be merged into the hipBLASLt source and require recompilation.

  • UpdateGrid: If enabled, the tool compares tuned results to existing grid-point solutions and replaces them only if a better-performing solution is found.

Grid and Equality in hipBLASLt#

When the input size does not match equality, a grid heuristic algorithm will select the optimal kernel for it.

This hybrid design balances coverage and precision, enabling developers to focus tuning on their most critical problem sizes while still benefiting from generalized performance elsewhere.

The Tuning Parameters#

Currently, SplitK is the only supported parameter under TuningParameters, but more tuning controls are expected in future releases.

What is SplitK?#

SplitK enables splitting the K dimension of the GEMM problem across multiple Compute Units (CUs) in the GPU, allowing for greater parallelism.

Why is SplitK useful?#

Consider the following case:

  • Target GPU: MI300 with 304 Compute Units

  • GEMM shape: M = 1280, N = 1280, K = 9000

  • Kernel MacroTile: 128 x 128

Without SplitK, the number of active tiles is:

(1280 / 128) * (1280 / 128) = 10 * 10 = 100 CUs utilized

That’s only 100 out of 304 CUs, leaving much of the GPU underutilized.

With SplitK = 3, the K dimension is divided into three slices:

  • 0–2999

  • 3000–5999

  • 6000–8999

Each slice allows the same 100-tile workload to run in parallel across different K partitions, resulting in approximately 300 CUs active simultaneously.

This dramatically increases performance, especially for problems where K is large and M/N are small to moderate.

This is why SplitK is an essential tuning knob provided to developers.

Running the Script#

Once you have a ROCm-compatible system and hipBLASLt installed, run the script as follows:

python3 find_exact.py template.yaml build_folder output_folder

Argument Descriptions#

  • template.yaml: Path to the YAML file describing the problem sizes and tuning configuration.

  • build_folder: Path to the compiled hipBLASLt build directory.

  • output_folder: Path to the directory where the tuned solution YAMLs and timing results will be written.

The output YAML will be either an equality logic yaml or a grid logic yaml based on the configuration.

Example Use Cases#

Here’s when you should consider using find_exact.py:

  • Offline tuning: Pre-benchmarking exact workloads to hardcode optimal solutions.

  • Performance regression testing: Compare kernel choices and timings across ROCm versions or hardware.

  • Static kernel selection: For fixed-shape inference in AI models or scientific computing loops.

Summary#

find_exact.py is an officially supported and actively maintained tool in the hipBLASLt tuning ecosystem. It plays a key role in the offline tuning workflow, allowing developers to precisely tune performance-critical GEMM problem sizes and integrate those results directly into the library.

For use cases involving fixed problem sizes—common in deep learning inference, embedded workloads, and HPC kernels—offline tuning provides stable, repeatable performance optimization that persists across builds. While this approach requires recompilation after each ROCm upgrade, it gives developers full control over kernel selection and performance consistency.

Whether you’re preparing for deployment, optimizing for specific hardware, or comparing kernel performance across releases, find_exact.py is a valuable tool to include in your tuning pipeline. In our next post, we’ll introduce another method to tune GEMM problems without recompiling the library.
