hipCIM 26.06: GPU-Accelerated Whole-Slide Image I/O on AMD Instinct™ GPUs

hipCIM 26.06: GPU-Accelerated Whole-Slide Image I/O on AMD Instinct™ GPUs#

hipCIM 26.06: GPU-Accelerated Whole-Slide Image I/O on AMD Instinct™ GPUs
October 20, 2026 by Soumitra Chatterjee, Vikas C Sajjan, Nilaykumar K Patel, Prateek Chokse, Anik Chaudhuri, Marco Grond, Vish Vadlamani, Phani Vaddadi.
10 min read. | 2532 total words.
Software tools & optimizations
AI/ML, Computer Vision, Performance
AI, Developers, Data Science

Every whole-slide image tells a story in pixels. A whole-slide image is a glass pathology slide scanned into a single very large digital image, stored as a pyramid of small tiles so a viewer can pan and zoom it. A single biopsy digitized at 20× magnification can span tens of thousands of pixels on each side and weigh in at several gigabytes. Before a model can learn anything from that slide, something has to read it off disk, decode its thousands of small JPEG-compressed tiles, and turn them into tensors the accelerator can work on. In digital pathology, that unglamorous first step is often where the wall-clock time quietly disappears.

This is the problem hipCIM was built to solve. With AMD Life Science 26.08, arriving alongside the ROCm™ 10.0 launch, AMD is introducing hipCIM 26.06.00, a substantial step forward for GPU-accelerated whole-slide image (WSI) I/O on AMD Instinct™ GPUs. hipCIM is the AMD port of cuCIM (RAPIDS) and a drop-in replacement for it: it speaks the same from cucim import CuImage API, so existing image-I/O code moves across unchanged, with no porting required, while decoded pixels land resident on the AMD GPU, ready for whatever comes next. This release targets ROCm 10.0: the amd-hipcim wheel is published against the ROCm 10.0 package index, so a ROCm 10.0 installation is what it expects.

If this is your first encounter with the library, an earlier post, Announcing hipCIM: A Cutting-Edge Solution for Accelerated Multidimensional Image Processing from July 2025 covers the fundamentals: supported formats, the Python and C++ APIs, and the initial release. This post covers what is new in 26.06.00: how fast it reads, how faithfully it decodes, and the broad set of real-world slide formats it can now open.

The Short Version#

On AMD Instinct™ MI355X with ROCm 10.0, hipCIM’s GPU path reads tiled whole-slide images at about 10× the OpenSlide throughput, and its CPU path at 7–11×, both measured on the same node. Speed is only part of the story. This release also hands back decoded pixels that stay resident in GPU memory, and it hands them to ROCm array libraries (CuPy, PyTorch-ROCm) with zero-copy interop: the downstream library reads the same GPU buffer directly, with no host round-trip and no second copy. It keeps GPU decode faithful to the CPU reference for JPEG-compressed slides, with a maximum absolute difference of 1 on 8-bit values for Aperio SVS, the slide format written by Leica Aperio scanners and one of the most common in digital pathology. It widens OME-TIFF (the Open Microscopy Environment’s multi-page TIFF format for microscopy images) coverage across the test corpus from 0.8% to 90.3%, and it hardens the trickier corners of the Aperio SVS and JPEG2000 formats. Table 1 summarizes the results.

Metric

hipCIM

Baseline

Speedup (ratio)

WSI GPU patch read, Aperio Carnegie Mellon University (CMU)-1/2/3.svs (MI355X, ROCm 10.0)

9,661–9,930 p/s

OpenSlide ~950 p/s

~10×

WSI CPU patch read, Aperio CMU-1/2/3.svs (MI355X, ROCm 10.0)

6,948–7,440 p/s

OpenSlide ~950 p/s

7–8×

WSI CPU patch read, GenericTIFF CMU-1 (MI355X, ROCm 10.0)

10,326 p/s

OpenSlide ~950 p/s

11×

GPU decode fidelity vs CPU reference, Aperio SVS (JPEG)

max abs diff = 1 (8-bit)

libjpeg-turbo

faithful

GPU decode fidelity, GenericTIFF CMU-1

max abs diff = 32, mean 0.13

libjpeg-turbo

bounded (98% ±1)

OME-TIFF corpus coverage

90.3%

prior hipCIM 0.8%

new

Table 1. Summary of the results in this post. Each row is detailed in the sections below.

Why Whole-Slide I/O Sits on the Critical Path#

It’s tempting to assume that a deep-learning pipeline spends most of its time in the model. In digital pathology, that assumption often breaks down. A whole-slide image is stored as a pyramid of small tiles, typically 256×256 pixels, each independently JPEG-compressed, and training or inference samples these tiles by the thousand. The library responsible for turning “a slide on disk” into “tensors on the accelerator” therefore sits squarely on the critical path: if it stalls, the GPU waits.

hipCIM’s job is to keep that path clear on AMD Instinct™, and with 26.06.00 it does so on the ROCm 10.0 platform, the software foundation for AMD Instinct™ MI355X.

Measuring Against OpenSlide#

To characterize I/O performance, the benchmark reads every non-overlapping 256×256 patch from a whole-slide image and compares against OpenSlide, the de-facto CPU reference for WSI reading. This workload is the one the field has standardized on: it’s reproducible, runs on any hardware without special provisioning, and gives a transparent, portable way to state throughput.

The test setup ran on an AMD Instinct™ MI355X (gfx950), bare-metal, with ROCm 10.0 and the hipCIM 26.06.00 wheel. The GPU path uses read_region(..., device="cuda") with rocJPEG hardware decode; the CPU path uses read_region(..., device="cpu") with the libjpeg-turbo backend. For each slide the benchmark reads every non-overlapping 256×256 patch at level 0, a 24×24 grid of 576 patches, with a warm cache, and reports the median of five trials. GPU, CPU, and the OpenSlide baseline were all measured in the same run.

hipCIM on AMD Instinct™ MI355X#

Table 2 reports patch-read throughput in patches per second, where higher is better, across the standard CMU test slides.

Slide

hipCIM-GPU (patches/s)

hipCIM-CPU (patches/s)

OpenSlide (patches/s)

GPU vs OpenSlide (ratio)

CPU vs OpenSlide (ratio)

Aperio CMU-1.svs

9,930

6,948

943

10.5×

7.4×

CMU-2.svs

9,661

7,362

951

10.2×

7.7×

CMU-3.svs

9,751

7,440

951

10.3×

7.8×

GenericTIFF CMU-1

9,578

10,326

943

10.2×

10.9×

Table 2. Patch-read throughput in patches per second. All GPU, CPU, and OpenSlide numbers come from the same MI355X with ROCm 10.0 run (5-trial median). The three Aperio SVS slides cluster tightly at 9,661–9,930 p/s GPU, a consistent ~10× over OpenSlide. GenericTIFF shows slightly higher CPU than GPU throughput on this 256×256 small-tile workload; this is expected, as explained in the next section.

The CPU path, at 7–11× over OpenSlide on the same MI355X node running ROCm 10.0, remains a meaningful win for workloads that do not require GPU-resident output.

Speed only counts if the pixels are right. For JPEG-compressed Aperio SVS slides, hipCIM’s rocJPEG hardware decode agrees with libjpeg-turbo to a maximum absolute difference of 1 on 8-bit values, the kind of off-by-one that rounding, not error, produces. For GenericTIFF, the distribution is tight: 98% of pixels are identical or differ by only ±1, with a mean difference of 0.13. The maximum absolute difference of 32 reflects a thin outlier tail. That bounded difference is reported plainly, and work continues to characterize GPU decode accuracy on the tiled-TIFF path.

GPU Versus CPU Throughput: What to Expect#

A careful reader will notice that hipCIM’s GPU and single-thread CPU paths sit much closer to each other than either does to OpenSlide. The GPU path is faster on the three Aperio SVS slides (≈9,900 vs ≈7,000 p/s); on the small-tile GenericTIFF case the CPU edges ahead. This is expected and inherent in the problem. GPU JPEG decode shines when it has a few large images to chew through; a 256×256 tile is tiny, and libjpeg-turbo decodes one with very little per-image overhead, so a CPU thread gets through them quickly. An independent benchmark from the hi-ml project (Microsoft Research) saw the same pattern on a full tiling workload at 224×224 tiles. This closeness on raw patches-per-second is a property of the many-small-tile nature of WSI reading itself, not of any one implementation.

So why report the GPU path at all? Because raw patches-per-second on this micro-benchmark is not where its advantage lies. That advantage is architectural, and the next section turns to it.

The Advantage That Matters: Zero-Copy, On-Device Pixels#

When you read with device="cuda", hipCIM hands back decoded pixels that are already resident in GPU memory, exposed through the standard __cuda_array_interface__. A downstream GPU consumer, whether CuPy, PyTorch-ROCm, or a model already sitting on the device, can pick them up with a zero-copy handoff, with no host round-trip. The CPU path, by contrast, must copy every tile from host to device before any GPU compute can begin.

For an end-to-end pipeline that feeds a GPU-resident model, this is the difference between decoded tiles that never leave the accelerator and tiles that shuttle back and forth across the PCIe bus. On AMD Instinct™ MI355X, with its large HBM3e memory, far more tiles can stay resident at once, which translates directly into higher sustained throughput for the GPU compute that follows. This is the architecture hipCIM’s GPU path is built around, and its payoff compounds across the rest of the AMD Life Science medical-imaging stack.

In practice this is a two-line change: read the region on the device, then hand the result to a GPU array library. The example below does exactly that.

from cucim import CuImage
import cupy as cp

img = CuImage("CMU-1.svs")

# Decode a tile straight onto the GPU, with no host round-trip
region = img.read_region(location=[50000, 40000], size=(512, 512), device="cuda")

# Zero-copy into CuPy via __cuda_array_interface__
tile = cp.asarray(region)

Reading More of the Real World#

Throughput means nothing if the library can’t open the file in the first place, and in practice, real slide archives are full of format quirks. A major thread of work in 26.06.00 was widening what hipCIM can read on AMD:

  • Multi-IFD OME-TIFF. Multi-IFD layouts used to be rejected outright. A single such layout triggered an exception that failed the whole file. That’s fixed: the complete 90-file OME-TIFF reference corpus now loads end to end. The impact on real archives is even more striking. Measured across a separate, much larger 2,703-file test set, readable coverage climbed from 0.8% to 90.3%, turning a format hipCIM could barely touch into one it reads across most of that set.

  • Aperio SVS abbreviated-JPEG. SVS tiles store their JPEG quantization and Huffman tables once per IFD, a format known as abbreviated JPEG (ITU-T T.81 §B.5). hipCIM now splices those tables back into each tile before handing it to rocJPEG so rocJPEG can decode the tile in hardware, and a single corrupt tile no longer takes down the whole host process.

  • Aperio JPEG2000 SVS. The device="cuda" path no longer aborts on JP2K slides; it decodes them on the CPU and stages the result to the device.

  • Hardened batched GPU reads. A class of host-process crashes on spatially-scattered batched reads, exactly the access pattern random patch samplers use during training, is fixed. The read path now gathers tiles per batch, which eliminates whole-slide-span over-reads, works through the page cache, and overlaps I/O latency with parallel per-tile reads.

  • Correct 64-bit integer handling. An int64/uint64 correctness bug could silently corrupt values above 2⁵³, the sort of defect that produces wrong results with no error at all. It’s fixed, so correctness holds even at the extremes of the integer range.

This release isn’t a marginal gain. GPU decode of JPEG-compressed Aperio SVS slides is new in 26.06.00, and every GPU number in this blog rests on it: this is the release that makes the GPU path functional, correct, and fast on real-world slides.

What Is Not Here Yet#

For completeness, a few limitations remain in this release:

  • JPEG2000 whole-slide decode is handled on the CPU for now; DICOM JP2K pixel data is decoded on the CPU and staged to the device.

  • GPUDirect Storage (GDS/cuFile) is stubbed and disabled in this release.

  • The amd-cupy sparse path has gaps: spsolve() raises NotImplementedError, and random_walker()’s bf mode is unavailable.

  • rocJPEG decode resolution is bounded to 64–16384 px.

Try It#

from cucim import CuImage
img = CuImage("CMU-1.svs")
print("Dimensions:", img.size())
region = img.read_region(location=[0, 0], size=(1024, 1024), level=0, device="cuda")

Install: python3 -m pip install amd-hipcim --extra-index-url https://pypi.amd.com/rocm-10.0.0/simple/

Where This Fits#

hipCIM is the foundation of the AMD Life Science medical-imaging stack, the layer that gets pixels onto the GPU quickly and correctly. Everything above it, from MONAI’s data loaders to the Model Zoo’s validated inference bundles, benefits from this fast foundation layer. If you’re moving a digital pathology or radiology workload to AMD Instinct™, hipCIM is where that journey begins.

Summary#

This blog showed how hipCIM 26.06.00 turns whole-slide image I/O into a GPU-resident operation on AMD Instinct™ GPUs. On MI355X with ROCm 10.0 it reads tiled slides about 10 times faster than OpenSlide on the GPU path and 7 to 11 times faster on the CPU path, decodes Aperio SVS faithfully to the CPU reference, widens OME-TIFF coverage from 0.8% to 90.3% of the test corpus, and hands tiles to ROCm array libraries with no host round-trip. Because it keeps the from cucim import CuImage API, your existing image-I/O code moves across unchanged. The win is faster, GPU-resident pixels for the same code you already run.

For digital pathology and radiology teams, that means the read step stops being the bottleneck and the accelerator spends its time on the model instead of waiting on I/O. This is the foundation layer of the AMD Life Science medical-imaging stack, and the layers above it are MONAI data loading, validated Model Zoo inference, and interactive annotation. Companion posts will cover each of those as they publish. Follow the AMD ROCm Blogs for the rest of the series and for the GPU-resident features still planned, including JPEG2000 GPU decode and GPUDirect Storage.

Additional Resources#

System Configuration#

All results in this post, covering the GPU path, the CPU path and the OpenSlide baseline, come from a single run on the configuration below.

Component

Configuration

GPU

AMD Instinct™ MI355X (gfx950), bare metal

ROCm

10.0

hipCIM

26.06.00

GPU JPEG decode

rocJPEG, VA-API hardware decode

CPU decode backend

libjpeg-turbo

OpenSlide baseline

run on the same node

The host CPU, operating system, amdgpu driver version and container image digest were not recorded for this run, so they are omitted rather than inferred.

Benchmark. 576 non-overlapping 256×256 patches per slide, a 24×24 grid at level 0, read sequentially per region with a warm cache, reporting the median of five trials. Aperio CMU-1/2/3.svs and GenericTIFF CMU-1 come from the OpenSlide test collection, licensed CC0-1.0. The GPU result was independently reproduced on 2 September 2026 on a separate MI355X node, at 9,411–10,450 patches/s.
