Vision-language models (VLMs) power applications from image captioning to robotics instruction following, but full model fine-tuning is resource-intensive and slow. Low-Rank Adaptation (LoRA) offers a faster, more efficient alternative by training only a small set of injected parameters while keeping the base model frozen.

This tutorial walks you through fine-tuning LoRA layers for an OpenCLIP vision-language model on AMD GPUs using ROCm’s developer tools, specifically the Enterprise AI Suite. You’ll learn how to inject LoRA layers into a pretrained model, train them on custom image-text pairs, and run inference with your fine-tuned weights. By the end, you’ll have a working example using the BridgeData robotics dataset and a reusable pipeline for your own data.

We’ll be using the Silogen AI Workloads repo for this tutorial, which contains workloads, tools, and utilities for AI development and testing in the AMD Enterprise AI Suite. You can read more from this blog post about the AMD Enterprise AI Suite.

Run this workflow on a Kubernetes cluster with AMD GPUs, or adapt the steps for a local ROCm environment. Let’s get started.

Prerequisites#

Before you begin, ensure that you have:

Environment Setup#

Verify ROCm Installation#

Check that ROCm is installed and your GPU is visible:

rocm-smi

You should see your AMD GPU listed with driver and firmware versions. If not, revisit the ROCm Installation Guide.

Clone the Workload Repository#

This tutorial uses a modified version of the clipora repository. Clone the workload files (including Docker configuration and Helm charts):

git clone https://github.com/silogen/ai-workloads.git
cd ai-workloads

The repository includes:

  • docker/vlm-lora-finetune/: Dockerfile and dependencies for building the container image

  • workloads/vlm-lora-finetune/helm/: Kubernetes Helm chart for running the fine-tuning job

  • workloads/vlm-lora-finetune/helm/mount/bridge_train_config.yml: Example training configuration for the BridgeData V2 dataset

Build the Docker Image (Optional)#

If you need to customize the environment, build the Docker image:

cd docker/vlm-lora-finetune
docker build -t vlm-lora-finetune:latest .

The image includes PyTorch with ROCm support, OpenCLIP, Hugging Face PEFT, and the clipora training scripts.

Understanding LoRA Fine-Tuning for Vision-Language Models#

Low-Rank Adaptation (LoRA) is a parameter-efficient fine-tuning technique. Instead of updating all model weights, LoRA injects small, trainable low-rank matrices into the model’s layers. This approach:

  • Reduces training time: Only a fraction of parameters are updated.

  • Saves memory: The base model remains frozen, which leads to reduced memory needed for storing gradients and optimizer states.

  • Enables easy sharing: LoRA weights are small and can be distributed independently of the base model.

For vision-language models like OpenCLIP, LoRA is ideal when you want to adapt a pretrained model to a specific domain (e.g., robotics instructions) without the cost of full fine-tuning.

Workflow Overview#

  1. Load a pretrained OpenCLIP model (e.g., ViT-L-14 with datacomp_xl_s13b_b90k weights).

  2. Inject LoRA layers into the model using Hugging Face PEFT.

  3. Fine-tune only the LoRA layers on your custom image-text dataset.

  4. Save the LoRA weights separately from the base model.

  5. Run inference by loading the base model and merging the fine-tuned LoRA weights.

Fine-tuning OpenCLIP with BridgeData V2#

The included Helm example uses a subset of the BridgeData V2 robotics dataset, available on Hugging Face. The dataset contains robot trajectory images paired with language instructions.

The workload includes a preprocessing script that:

  1. Downloads the BridgeData TFRecords.

  2. Extracts images and language instructions.

  3. Converts the data to the CSV format required by OpenCLIP.

You don’t need to understand the preprocessing script in detail, it’s a one-time conversion step specific to BridgeData.

Using Your Own Dataset#

To use your own data:

  1. Organize your images in a directory accessible to the training job.

  2. Create train and evaluation CSV files in the OpenCLIP format, as is done in the abovementioned preprocessing script.

  3. Create a custom config file based on mount/bridge_train_config.yml to update the train_dataset and eval_dataset paths:

train_dataset: "/path/to/your/train.csv"
eval_dataset: "/path/to/your/eval.csv"

Configuring the Training Job#

Training parameters are defined in mount/bridge_train_config.yml. Key settings include:

  • Model: Base OpenCLIP model and pretrained weights (e.g., ViT-L-14 with datacomp_xl_s13b_b90k)

  • LoRA rank: Controls the size of the LoRA matrices (higher rank = more parameters)

  • Batch size: Number of samples per training step

  • Learning rate: Step size for gradient updates

  • Epochs: Number of passes through the training data

  • Output directory: Where to save LoRA weights and checkpoints

Review and adjust these settings based on your dataset size and available GPU memory. For example:

model: "ViT-L-14"
pretrained: "datacomp_xl_s13b_b90k"
lora_rank: 8
batch_size: 32
learning_rate: 1e-4
epochs: 3
output_dir: "/workload/bridge_output"

Running the Fine-Tuning Job on Kubernetes#

The Helm chart in the helm/ directory provides a complete Kubernetes job definition for fine-tuning.

Step 1: Deploy the Job#

Replace username_here with your preferred user ID and deploy the job:

cd ai-workloads/vlm-lora-finetune/helm
helm template workloads/vlm-lora-openclip . --set metadata.user_id=username_here | kubectl apply -f -

This command:

  • Renders the Helm template with your user ID.

  • Creates a Kubernetes job that runs the fine-tuning workflow on an AMD GPU node.

Step 2: Monitor the Job#

Get the pod name for your training job:

kubectl get pods

Look for a pod starting with vlm-lora-finetuning-job-{user_id}:

NAME                                           READY   STATUS    RESTARTS   AGE
vlm-lora-finetuning-job-{user_id}-{pod_hash}   1/1     Running   0          86s

If the STATUS is stuck in Pending, check the job with kubectl describe pod vlm-lora-finetuning-job-{user_id}-{pod_hash} to debug. Make sure that the storageClassName is set to standard in ai-workloads/vlm-lora-finetune/helm/values.yaml file:

storage:
  ephemeral:
    quantity: 100Gi
    storageClassName: standard
    accessModes:
      - ReadWriteOnce
  dshm:
    sizeLimit: 32Gi

When the STATUS is Running, check the logs to monitor training progress:

kubectl logs vlm-lora-finetuning-job-{user_id}-{pod_hash}

Training has started successfully when you see an output similar to:

INFO:root:Loaded ViT-L-14 model config.
INFO:root:Loading pretrained ViT-L-14 weights (datacomp_xl_s13b_b90k).
Starting clipora training with config: /mounted-files/bridge_train_config.yml

Output directory: /workload/bridge_output
Using seed 1337
***** Running training *****
  Using device: cuda
  Num Iters = 56
  Num Epochs = 3
  Instantaneous batch size per device = 32
  Gradient Accumulation steps = 1

Note: Logs may take 1–2 minutes to appear. Training on the example dataset takes approximately 15 minutes on Instinct™ MI300X GPUs. You may see warnings about deprecated imports or missing CUDA drivers, these can be safely ignored in a ROCm environment.

Step 3: Retrieve Results#

By default, the job pod remains active for 10 minutes after completion, allowing you to copy results to your local machine:

kubectl cp vlm-lora-finetuning-job-{user_id}-{pod_hash}:/workload/bridge_output bridge_output

The bridge_output directory contains:

  • LoRA configuration: JSON file with LoRA hyperparameters

  • Training configuration: YAML file with the clipora training settings used

  • LoRA weights: PyTorch checkpoint files with the fine-tuned LoRA parameters

  • Evaluation results: Metrics and visualizations comparing the original and fine-tuned models

Understanding the Training Output#

Saved Artifacts#

After training completes, inspect the output directory:

ls bridge_output/

You’ll find:

  • Checkpoint folders (and final) containing:

    • adapter_config.json: LoRA adapter configuration (rank, target modules, etc.)

    • adapter_model.safetensors: Fine-tuned LoRA weights

    • train_config.yml: Copy of the training configuration used

  • output_image.png: Sample predictions comparing original vs. fine-tuned model

Evaluation Metrics#

The training script automatically runs inference on the evaluation set using both the original pretrained model and the fine-tuned LoRA model. Example output:

Running inference comparison...
Original eval loss:
{'eval_loss': tensor(4.7737)}
Lora eval loss:
{'eval_loss': tensor(0.4188)}

The dramatic reduction in evaluation loss (from 4.77 to 0.42) demonstrates that the LoRA layers have successfully adapted the model to the robotics instruction domain.

Prediction Probabilities#

The script also outputs prediction probabilities for a sample from the evaluation set:

Visualizing results...
probs before:
[2.57515550e-01 1.46542358e-14 7.42484391e-01 3.23128511e-17
 5.35866707e-12 8.72237192e-25 6.95570677e-08 7.13214876e-10
 3.27358718e-13 1.16048234e-10]
probs after:
[9.9999988e-01 1.3494220e-27 1.3096904e-07 1.7481791e-22 4.6080438e-26
 3.9263898e-32 4.6212802e-19 5.2853294e-17 1.5104853e-20 2.8321767e-16]

Before fine-tuning, the model’s confidence is split across multiple candidates. After LoRA fine-tuning, the model assigns nearly 100% probability to the correct instruction, showing strong adaptation to the task.

This approach allows you to:

  • Share only the small LoRA weights (typically a few MB) instead of the entire model (several GB)

  • Quickly switch between different LoRA adaptations for the same base model

  • Deploy fine-tuned models with minimal storage overhead

Troubleshooting Common Issues#

GPU Not Detected#

Symptom: Training fails with “No GPU available” or similar error.

Solution: Verify ROCm installation and GPU visibility:

rocm-smi
echo $ROCR_VISIBLE_DEVICES

Ensure your Kubernetes node has the AMD GPU operator installed and the pod has requested GPU resources in the Helm chart.

Out of Memory Errors#

Symptom: Training crashes with CUDA/HIP out-of-memory errors.

Solution: Reduce batch size in bridge_train_config.yml:

batch_size: 16  # Reduce from 32

Or enable gradient accumulation to maintain effective batch size:

gradient_accumulation_steps: 2

Gradient accumulation allows you to maintain a large effective batch size even when GPU memory limits force you to use smaller mini-batches. Instead of updating the model weights after each small mini-batch, you run multiple forward and backward passes while accumulating (summing) the gradients, then perform a single weight update after processing all the mini-batches.

Slow Training Progress#

Symptom: Training takes much longer than expected.

Solution:

  • Verify you’re using GPU acceleration (check logs for “Using device: cuda”)

  • Reduce dataset size for initial testing

  • Check GPU utilization with rocm-smi during training

  • Consider using a smaller base model (e.g., ViT-B-32 instead of ViT-L-14)

CSV Parsing Errors#

Symptom: Training fails with “Unable to read CSV” or similar.

Solution: Verify your CSV format:

  • Ensure column headers are exactly image_path and language_instruction

  • Check that all image paths are absolute and accessible from the container

  • Validate that there are no missing values or malformed rows

Adapting This Workflow for Your Use Case#

Fine-Tuning for Different Domains#

This tutorial uses robotics instructions, but the same workflow applies to other vision-language tasks:

  • Product search: Image-text pairs of products and descriptions

  • Medical imaging: Radiology images with diagnostic reports

  • Accessibility: Images paired with detailed alt-text descriptions

  • Content moderation: Images with policy-compliant descriptions

Simply prepare your dataset in the CSV format mentioned below and adjust the training configuration.

Dataset Format#

OpenCLIP and clipora expect a CSV file with two columns:

  • image_path: Path to the image file

  • language_instruction: Text description or instruction corresponding to the image

Example CSV:

image_path,language_instruction
"/data/episode_0006/step_0037.png","put the cube on top of the cylinder"
"/data/episode_0048/step_0010.png","Move the blue spoon to the left burner"
"/data/episode_0046/step_0031.png","take the yellow cube and move it to the left"

You’ll need separate CSV files for training and evaluation.

Experimenting with LoRA Hyperparameters#

Key LoRA parameters to experiment with:

LoRA Rank (lora_rank):

  • Lower rank (4-8): Fewer parameters, faster training, less expressive

  • Higher rank (16-32): More parameters, slower training, more expressive

  • Start with rank 8 and increase if performance plateaus

Target Modules (target_modules):

  • Specify which model layers receive LoRA adapters

  • Default targets attention layers (most impactful for vision-language models)

  • Expand to MLP layers for more adaptation capacity

Alpha Parameter (lora_alpha):

  • Controls the scaling of LoRA updates

  • Typically set to 2× the rank (e.g., alpha=16 for rank=8)

  • Higher alpha = stronger LoRA influence

Example configuration:

lora_rank: 16
lora_alpha: 32
target_modules: ["q_proj", "v_proj", "k_proj", "out_proj"]

Memory Requirements#

Approximate GPU memory usage:

  • ViT-B-32 with LoRA (rank 8): ~8 GB

  • ViT-L-14 with LoRA (rank 8): ~16 GB

  • ViT-H-14 with LoRA (rank 8): ~24 GB

Reduce batch size or use gradient checkpointing if you encounter out-of-memory errors.

Gradient checkpointing (also called activation checkpointing) reduces memory usage during training by trading computation for memory. During the forward pass, instead of storing all intermediate activations needed for backpropagation, the technique only saves activations at certain checkpoints and discards the rest. This technique is particularly valuable for training very deep networks or large models (like transformers) where activation memory, not model parameters, becomes the primary memory bottleneck.

Summary#

In this tutorial, you learned how to fine-tune vision-language models efficiently using LoRA on AMD GPUs with ROCm. You walked through the complete workflow: preparing image-text datasets in CSV format, configuring LoRA hyperparameters, running distributed training jobs on Kubernetes, and validating your fine-tuned models.

Key takeaways:

  • LoRA enables efficient fine-tuning: Train only a small fraction of parameters while keeping the base model frozen, reducing time and memory requirements.

  • OpenCLIP provides strong pretrained models: Leverage models like ViT-L-14 pretrained on billions of image-text pairs as your starting point.

  • Custom datasets are straightforward: Convert your image-text pairs to CSV format and adjust the training configuration.

  • ROCm delivers GPU acceleration: AMD GPUs with ROCm provide the compute power needed for vision-language model fine-tuning.

  • LoRA weights are portable: Share and deploy small adapter files (a few MB) instead of multi-GB full models.

What you built:

  • A complete fine-tuning pipeline for OpenCLIP models with LoRA

  • A working example on the BridgeData robotics dataset

  • Reusable Kubernetes job templates for production workflows

  • Validation scripts to measure fine-tuning effectiveness

Interested in learning more about fine-tuning with ROCm? Check out the AMD Resource Manager & AMD AI Workbench Documentation for additional tutorials and advanced configurations. For low-code fine-tuning, check out the related content in the documentation.

With ROCm 7.0, AMD is releasing the Enterprise AI Suite to help enterprise customers address the growing need for AI infrastructure management. This release delivers two key components:

  • AMD Resource Manager: simplifying cluster-scale orchestration and optimizing AI workloads across Kubernetes and enterprise environments.

  • AMD AI Workbench: a flexible environment for deploying, adapting, and scaling AI models, with built-in support for inference, fine-tuning, and integration into enterprise workflows.

Sign up here for early access to explore these AMD Enterprise AI tools. You’ll need to create an AMD account to continue with the sign-up form.

By embracing open-source principles, AMD ensures transparency, flexibility, and ecosystem collaboration — helping enterprises build intelligent, autonomous systems that deliver real-world impact.

Further Reading#

AMD ROCm Resources#

OpenCLIP and Vision-Language Models#

LoRA and Parameter-Efficient Fine-Tuning#

Datasets#

Disclaimers#

Third-party content is licensed to you directly by the third party that owns the content and is not licensed to you by AMD. ALL LINKED THIRD-PARTY CONTENT IS PROVIDED “AS IS” WITHOUT A WARRANTY OF ANY KIND. USE OF SUCH THIRD-PARTY CONTENT IS DONE AT YOUR SOLE DISCRETION AND UNDER NO CIRCUMSTANCES WILL AMD BE LIABLE TO YOU FOR ANY THIRD-PARTY CONTENT. YOU ASSUME ALL RISK AND ARE SOLELY RESPONSIBLE FOR ANY DAMAGES THAT MAY ARISE FROM YOUR USE OF THIRD-PARTY CONTENT.

Contents
