Finite difference method  Laplacian part 2#
4 Jan, 2023 by Justin Chang, Rajat Arora, Thomas Gibson, Sean Miller, Ossian O’Reilly.
Note: This blog was previously part of the AMD lab notes blog series.
In the previous Laplacian post, we developed a HIP implementation of a finitedifference stencil code designed around a Laplace operator. The initial implementation was found to be memory bandwidth bound, meaning that its runtime was limited by the rate at which we could move data to and from global memory. Furthermore, the current memory access pattern requires multiple trips to global memory to load all data, so the execution time could be reduced if we cache more of the data. We established the figure of merit (FOM) as effective memory bandwidth which divides the theoretical memory movement divided by the actual execution time. The FOM of our HIP implementation currently achieves 50%[1] of the peak of a single MI250X GCD, but our analysis suggests that bringing the actual memory movement down to the theoretical amount may allow our FOM to reach at least 71%[1] of the peak. In this post we will introduce two common optimizations that can be applied to the kernel to help achieve this:
Loop tiling to explicitly reduce memory loads
Reorder the memory access pattern to improve caching
Review#
In the previous post, we considered a HIP implementation of the central finite difference stencil for the Laplacian. Recall that the Laplacian takes the form of a divergence of a gradient of a scalar field \(u(x,y,z)\):
The initial HIP implementation is shown below
template <typename T>
__global__ void laplacian_kernel(T * f, const T * u, int nx, int ny, int nz, T invhx2, T invhy2, T invhz2, T invhxyz2) {
int i = threadIdx.x + blockIdx.x * blockDim.x;
int j = threadIdx.y + blockIdx.y * blockDim.y;
int k = threadIdx.z + blockIdx.z * blockDim.z;
// Exit if this thread is on the boundary
if (i == 0  i >= nx  1
j == 0  j >= ny  1
k == 0  k >= nz  1)
return;
const int slice = nx * ny;
size_t pos = i + nx * j + slice * k;
// Compute the result of the stencil operation
f[pos] = u[pos] * invhxyz2
+ (u[pos  1] + u[pos + 1]) * invhx2
+ (u[pos  nx] + u[pos + nx]) * invhy2
+ (u[pos  slice] + u[pos + slice]) * invhz2;
}
template <typename T>
void laplacian(T *d_f, T *d_u, int nx, int ny, int nz, int BLK_X, int BLK_Y, int BLK_Z, T hx, T hy, T hz) {
dim3 block(BLK_X, BLK_Y, BLK_Z);
dim3 grid((nx  1) / block.x + 1, (ny  1) / block.y + 1, (nz  1) / block.z + 1);
T invhx2 = (T)1./hx/hx;
T invhy2 = (T)1./hy/hy;
T invhz2 = (T)1./hz/hz;
T invhxyz2 = 2. * (invhx2 + invhy2 + invhz2);
laplacian_kernel<<<grid, block>>>(d_f, d_u, nx, ny, nz, invhx2, invhy2, invhz2, invhxyz2);
}
and the corresponding performance on a single MI250X GCD:
$ ./laplacian_dp_kernel1
Kernel: 1
Precision: double
nx,ny,nz = 512, 512, 512
block sizes = 256, 1, 1
Laplacian kernel took: 2.64172 ms, effective memory bandwidth: 808.148 GB/s
The reported 808.148 GB/s
meets 69.4% of the target we established in the previous post.
We will continue to use rocprof
to help us gauge the effectiveness of each of the following optimizations.
In the previous post, we can infer that the f
device array is efficiently stored because the WRITE_SIZE
metric
matches the theoretical. However, the reported FETCH_SIZE
is almost double the theoretical amount and
therefore there can be an opportunity to improve performance if this data size could be reduced.
Recall that seven elements from the u
array are loaded to update each entry in the f
array
but each of those u
elements could be reused up to six times by neighboring grid points.
It is important to note that from a wavefront perspective,
the load for each entry in u
is a contiguous chunk of 64 entries. Our current thread block configuration
(256 \(\times\) 1 \(\times\) 1) loads four waves of elements along the x
direction, providing an opportunity
for threads in a single wave to cache and reuse x
elements for x  1
and x + 1
stencil computations.
However, loading waves in the y
and z
directions must be implemented carefully to maximize
spatial locality and reuse values from neighboring waves and thread blocks.
Thus, we focus our attention on optimizing loads in one of these two directions through loop tiling.
Loop tiling#
As it stands, each thread computes a stencil
around a single grid point. What happens if we let each thread compute stencils of multiple grid points?
This will require more load instructions per thread but due to the
contiguous nature of the threading,
these loads will be more likely to reuse cached values for u
.
This optimization, known as loop tiling, will reduce
the number of thread blocks launched and increase the number of stencils
computed per thread.
Before we dive into the optimized Laplacian kernel, let us first consider a small example to further explain
the concept and benefit of loop tiling: Suppose we want to perform the strided computation
f[pos] = u[pos  1] + u[pos] + u[pos + 1]
. Without tiling, each thread would need to
perform three loads and one store instruction. It would be ideal if we could have each thread only load
one u
element and reuse the other two u
elements already loaded and stored in registers. In other words,
we should try to minimize the number of loads per store instruction per thread. If we tile by some factor,
let’s pick two, then each thread would perform two stores, but consider the number of loads:
f[pos] = u[pos  1] + u[pos] + u[pos + 1];
f[pos + 1] = u[pos] + u[pos + 1] + u[pos + 2];
Note that u[pos]
and u[pos + 1]
appear twice, which means we only need to load them once. This
observation allows us to reuse the previously loaded value. To make this point clear, we can introduce two variables:
double u0 = u[pos];
double u1 = u[pos + 1];
f[pos] = u[pos  1] + u0 + u1;
f[pos + 1] = u0 + u1 + u[pos + 2];
As a result, we have explicitly reduced the number of load instructions from 6 to 4 (i.e., reduction by 33%). We now have approximately 2 loads per store. See the table below to see how loop tiling factors correlate with the load store ratio.
Tile Factor
Loads
Stores
Ratio

1
3
1
3.00
2
4
2
2.00
4
6
4
1.50
8
10
8
1.25
16
18
16
1.13
Keep in mind that the increasing the tile factor increases the register use in the kernel which will reduce its occupancy. If the compiler runs out of registers, register spillage to global memory occurs which can negatively affect performance.
Circling back to the 3D Laplacian kernel, there are three potential directions for
loop tiling. Let us tile in the y
direction for demonstration.
Consider the figure below illustrating the reuse pattern:
Figure 1: Illustration of loop tiling for each thread on an xy
plane. The number of grid points loaded and reused depends on the tile width.
Let us denote the tile factor by m
, which is a user defined macro variable determined at compile time.
The code modifications for this kernel can be quite complex so we shall cover the changes in two
phases: setup and computation. First, we apply the following changes:
Kernel 1 setup (before)  Kernel 2 setup (after)

int j = threadIdx.y + blockIdx.y * blockDim.y;
...
// Exit if this thread is on the boundary
if (i == 0  i >= nx  1
j == 0  j >= ny  1
k == 0  k >= nz  1)
return;
...
dim3 grid((nx  1) / block.x + 1,
(ny  1) / block.y + 1,
(nz  1) / block.z + 1);

#define m 1
...
int j = m*(threadIdx.y + blockIdx.y * blockDim.y);
...
// Exit if this thread is on the xz boundary
if (i == 0  i >= nx  1
k == 0  k >= nz  1)
return;
...
dim3 grid((nx  1) / block.x + 1,
(ny  1) / (block.y * m) + 1,
(nz  1) / block.z + 1);

Kernel 2 introduces the macro variable m
which is used to divide the grid dimension in the
y
direction. Setting m=1
currently has no tiling effect  experimenting with other values
requires recompilation of the code. We removed the requirement that threads exit at
the y
boundary for the case where stencils overlap the boundary.
In our next set of code modifications, we focus on rewriting the f[pos] = ...
computation for
a tile factor m
. Because we are tiling in the y
direction, each thread strides pos
by nx
. These modifications are tricky so we will break it down into four steps:
Add a for loop to the main computational kernel
Introduce an array of size
m
to accumulate the running sum of the stencil pointsSplit the
u
element loads andf
element stores into separate loopsIntroduce a variable to hold a
u
element for reuse
Below are code snippets before and after the application of the four steps. We begin by wrapping our stencil evaluation in a for loop:
Kernel 1 computation  Step 0 (before)  Step 1 (after)

f[pos] = u[pos] * invhxyz2
+ (u[pos  1]
+ u[pos + 1]) * invhx2
+ (u[pos  nx]
+ u[pos + nx]) * invhy2
+ (u[pos  slice]
+ u[pos + slice]) * invhz2;

for (int n = 0; n < m; n++)
if (j + n > 0 && j + n < ny  1)
f[pos + n*nx] = u[pos + n*nx] * invhxyz2
+ (u[pos  1 + n*nx]
+ u[pos + 1 + n*nx]) * invhx2
+ (u[pos  nx + n*nx]
+ u[pos + nx + n*nx]) * invhy2
+ (u[pos  slice + n*nx]
+ u[pos + slice + n*nx]) * invhz2;

Introducing a for loop over a value m
known at compile time has similar effects to loop unrolling
where the compiler will minimize the overhead of looping. Keep in mind m
must not be too large
or the compiler will spill registers to global memory.
At this point, the kernel is technically tiled, however, a few more code modifications are needed to minimize the load to store ratio. Next we create an accumulation array:
Step 1 (before)  Step 2 (after)

for (int n = 0; n < m; n++)
if (j + n > 0 && j + n < ny  1)
f[pos + n*nx] = u[pos + n*nx] * invhxyz2
+ (u[pos  1 + n*nx]
+ u[pos + 1 + n*nx]) * invhx2
+ (u[pos  nx + n*nx]
+ u[pos + nx + n*nx]) * invhy2
+ (u[pos  slice + n*nx]
+ u[pos + slice + n*nx]) * invhz2;

T Lu[m] = {0};
for (int n = 0; n < m; n++)
if (j + n > 0 && j + n < ny  1) {
Lu[n] = u[pos + n*nx] * invhxyz2;
Lu[n] += (u[pos  1 + n*nx]
+ u[pos + 1 + n*nx]) * invhx2;
Lu[n] += (u[pos  nx + n*nx]
+ u[pos + nx + n*nx]) * invhy2;
Lu[n] += (u[pos  slice + n*nx]
+ u[pos + slice + n*nx]) * invhz2;
f[pos + n*nx] = Lu[n];
}

The accumulation array Lu
temporarily holds the sum of the computations. Note that we kept the original order of the stencil
computations  first load the x
direction stencils, then the y
direction stencils, and finally the z
direction stencils.
We will eventually revisit this ordering, but our next step is to split the load and store steps:
Step 2 (before)  Step 3 (after)

T Lu[m] = {0};
for (int n = 0; n < m; n++)
if (j + n > 0 && j + n < ny  1) {
Lu[n] = u[pos + n*nx] * invhxyz2;
Lu[n] += (u[pos  1 + n*nx]
+ u[pos + 1 + n*nx]) * invhx2;
Lu[n] += (u[pos  nx + n*nx]
+ u[pos + nx + n*nx]) * invhy2;
Lu[n] += (u[pos  slice + n*nx]
+ u[pos + slice + n*nx]) * invhz2;
f[pos + n*nx] = Lu[n];
}

T Lu[m] = {0};
for (int n = 0; n < m; n++)
if (j + n > 0 && j + n < ny  1) {
Lu[n] = u[pos + n*nx] * invhxyz2;
Lu[n] += (u[pos  1 + n*nx]
+ u[pos + 1 + n*nx]) * invhx2;
Lu[n] += (u[pos  nx + n*nx]
+ u[pos + nx + n*nx]) * invhy2;
Lu[n] += (u[pos  slice + n*nx]
+ u[pos + slice + n*nx]) * invhz2;
}
for (int n = 0; n < m; n++)
if (j + n > 0 && j + n < ny  1)
f[pos + n*nx] = Lu[n];

Splitting the loads and stores into separate for loops enables all Lu
elements to simultaneously
accumulate the stencil computations before writing to f
. The fourth and final change is to
explicitly remove load instructions by reusing loaded u
elements across different stencils.
Each iteration of n
still loads the x
direction and z
direction stencils for Lu[n]
but could now potentially reuse the u
element to compute y
direction stencils belonging
to Lu[n1]
and/or Lu[n+1]
:
Step 3 (before)  Kernel 2 computation  Step 4 (after)

T Lu[m] = {0};
for (int n = 0; n < m; n++)
if (j + n > 0 && j + n < ny  1) {
Lu[n] = u[pos + n*nx] * invhxyz2;
Lu[n] += (u[pos  1 + n*nx]
+ u[pos + 1 + n*nx]) * invhx2;
Lu[n] += (u[pos  nx + n*nx]
+ u[pos + nx + n*nx]) * invhy2;
Lu[n] += (u[pos  slice + n*nx]
+ u[pos + slice + n*nx]) * invhz2;
}
for (int n = 0; n < m; n++)
if (j + n > 0 && j + n < ny  1)
f[pos + n*nx] = Lu[n];

T center;
T Lu[m] = {0};
for (int n = 0; n < m; n++) {
center = u[pos + n*nx];
Lu[n] = center * invhxyz2
+ (u[pos  1 + n*nx]
+ u[pos + 1 + n*nx]) * invhx2;
if (n == 0)
Lu[n] += u[pos  nx + n*nx] * invhy2;
if (n > 0)
Lu[n1] += center * invhy2;
if (n < m  1)
Lu[n+1] += center * invhy2;
if (n == m  1)
Lu[n] += u[pos + nx + n*nx] * invhy2;
Lu[n] += (u[pos  slice + n*nx]
+ u[pos + slice + n*nx]) * invhz2;
}
for (int n = 0; n < m; n++)
if (j + n > 0 && j + n < ny  1)
f[pos + n*nx] = Lu[n];

Below is the full kernel 2 implementation capturing all the above code modifications:
// Tiling factor
#define m 1
template <typename T>
__global__ void laplacian_kernel(T * f, const T * u, int nx, int ny, int nz, T invhx2, T invhy2, T invhz2, T invhxyz2) {
int i = threadIdx.x + blockIdx.x * blockDim.x;
int j = m*(threadIdx.y + blockIdx.y * blockDim.y);
int k = threadIdx.z + blockIdx.z * blockDim.z;
// Exit if this thread is on the xz boundary
if (i == 0  i >= nx  1
k == 0  k >= nz  1)
return;
const int slice = nx * ny;
size_t pos = i + nx * j + slice * k;
// Each thread accumulates m stencils in the y direction
T Lu[m] = {0};
// Scalar for reusable data
T center;
// Loop tiling
for (int n = 0; n < m; n++) {
center = u[pos + n*nx]; // store for reuse
// x direction
Lu[n] += center *invhxyz2
+ (u[pos  1 + n*nx] + u[pos + 1 + n*nx]) * invhx2;
// y  1, first n
if (n == 0) Lu[n] += u[pos  nx + n*nx] * invhy2;
// reuse: y + 1 for prev n
if (n > 0) Lu[n1] += center * invhy2;
// reuse: y  1 for next n
if (n < m  1) Lu[n+1] += center * invhy2;
// y + 1, last n
if (n == m  1) Lu[n] += u[pos + nx + n*nx] * invhy2;
// z  1 and z + 1
Lu[n] += (u[pos  slice + n*nx] + u[pos + slice + n*nx]) * invhz2;
}
// Store only if thread is inside y boundary
for (int n = 0; n < m; n++)
if (j + n > 0 && j + n < ny  1)
f[pos + n*nx] = Lu[n];
}
template <typename T>
void laplacian(T *d_f, T *d_u, int nx, int ny, int nz, int BLK_X, int BLK_Y, int BLK_Z, T hx, T hy, T hz) {
dim3 block(BLK_X, BLK_Y, BLK_Z);
dim3 grid((nx  1) / block.x + 1, (ny  1) / (block.y * m) + 1, (nz  1) / block.z + 1);
T invhx2 = (T)1./hx/hx;
T invhy2 = (T)1./hy/hy;
T invhz2 = (T)1./hz/hz;
T invhxyz2 = 2. * (invhx2 + invhy2 + invhz2);
laplacian_kernel<<<grid, block>>>(d_f, d_u, nx, ny, nz, invhx2, invhy2, invhz2, invhxyz2);
}
Note that this kernel is currently written so that ny
must be divisible by block.y * m
.
Let us experiment with various values of m
compatible with our chosen problem size
and see whether loop tiling has any benefits.
Speedup
% of target


Kernel 1  Baseline
1.00
69.4%
Kernel 2  Loop tiling m=1
1.00
69.4%
Kernel 2  Loop tiling m=2
0.98
68.3%
Kernel 2  Loop tiling m=4
0.94
65.5%
Kernel 2  Loop tiling m=8
0.92
64.0%
Kernel 2  Loop tiling m=16
0.29
20.1%
It is strange that none of the examined m
provide any significant speedup.
In fact, increasing the tile factor appears to exacerbate the performance.
Let’s examine the FETCH_SIZE
and L2CacheHit
metrics for further insight:
FETCH_SIZE (GB)
Fetch efficiency (%)
L2CacheHit (%)


Theoretical
1.074


Kernel 1  Baseline
2.014
53.3
65.0
Kernel 2  Loop tiling m=1
2.014
53.3
65.0
Kernel 2  Loop tiling m=2
1.848
58.1
60.5
Kernel 2  Loop tiling m=4
1.880
57.1
57.0
Kernel 2  Loop tiling m=8
1.820
59.0
56.0
Kernel 2  Loop tiling m=16
5.637
19.1
40.9
The fetch efficiency only marginally increased whereas the L2 cache hit drops significantly.
We suspect the reason for this is that the accumulation steps follow the same access pattern
as the initial kernel. That is, we first compute the x
direction stencils, followed by
the potentially reusable y  1
and y + 1
stencils, and end with the z  1
and z + 1
stencils.
From a memory address perspective, the read access pattern jumps both forward and backward which
could have implications, as explained and addressed next.
Reorder read access patterns#
After the optimization, there is little to no speedup. While increasing the tile factor reduces
the loads per store ratio, it may not necessarily translate into a reduction in global data movement.
For FETCH_SIZE
to decrease, the data movement between L2 and global memory must decrease. As the load
per store ratio increases, the number of read requests sent to L1 must decrease and L2 as well (assuming
that the L1 cache hit ratio stays the same). Since we observe that FETCH_SIZE
stays the same and
that L2CacheHit
decreases, the optimization has reduced the pressure on the L2 cache (fewer
requests sent to it) but failed to improve the reuse of the data loaded from global memory into the
L2 cache. To understand why the previous kernel achieves suboptimal L2 data reuse, let us visualize
the 3D stencils and their read access patterns if m = 2
:
Figure 2: Finite difference stencil in 3D space with a tile factor of m = 2
. The black numbers represent the order each thread in Kernel 2 accesses elements of u
.
Figure 3: Kernel 2 memory access pattern of a single thread for the array u
with a tile factor of m = 2
. The numbers and black arrows correspond to the order the thread accesses elements of u
. The n = 0
and n = 1
rows represent u
elements needed for the stencil computation of grid points pos
and pos + nx
, respectively. The 1st accessed element (u[pos]
) is loaded during the n = 0
iteration and reused for the y  1
element of the n = 1
iteration. Likewise the 7th accessed element (u[pos + nx]
) is loaded during the n = 1
iteration and reused for the y + 1
element of the n = 0
iteration.
We immediately see a problem. The thread often needs to jump “backwards” in the memory space of the u
array.
After accessing each grid point’s z + 1
element, the thread needs to jump “backwards” to access
the x
direction elements for the next iteration of n
. Frequently accessing u
elements by going both forward
and backward in the memory address may prematurely evict reusable data from cache. We prefer to instead reorder the
instructions in the kernel to only use a single direction i.e., accessing memory by ascending address:
Figure 4: Finite difference stencil in 3D space with a tile factor of m = 2
. The black numbers represent the order each thread the proposed kernel accesses elements of u
.
Figure 5: Proposed memory access pattern of a single thread for the array u
with a tile factor of m = 2
. The numbers and black arrows correspond to the order the thread accesses elements of u
. The n = 0
and n = 1
rows represent u
elements needed for the stencil computation of grid points pos
and pos + nx
, respectively. The 5th accessed element (u[pos]
) is loaded during the n = 0
iteration and reused for the y  1
element of the n = 1
iteration. Likewise the 8th accessed element (u[pos + nx]
) is loaded during the n = 1
iteration and reused for the y + 1
element of the n = 0
iteration.
Under this different approach, we first access all z  1
elements, followed by the y  1
element of iteration n = 0
, all x
direction elements, the y + 1
element of iteration n = m  1
, and end with all z + 1
elements. Each thread now accesses all needed
u
elements by ascending memory address. A significant rewrite of the kernel is necessary, so we first present the full implementation:
// Tiling factor
#define m 1
template <typename T>
__global__ void laplacian_kernel(T * f, const T * u, int nx, int ny, int nz, T invhx2, T invhy2, T invhz2, T invhxyz2) {
int i = threadIdx.x + blockIdx.x * blockDim.x;
int j = m*(threadIdx.y + blockIdx.y * blockDim.y);
int k = threadIdx.z + blockIdx.z * blockDim.z;
// Exit if this thread is on the xz boundary
if (i == 0  i >= nx  1
k == 0  k >= nz  1)
return;
const int slice = nx * ny;
size_t pos = i + nx * j + slice * k;
// Each thread accumulates m stencils in the y direction
T Lu[m] = {0};
// Scalar for reusable data
T center;
// z  1, loop tiling
for (int n = 0; n < m; n++)
Lu[n] += u[pos  slice + n*nx] * invhz2;
// y  1
Lu[0] += j > 0 ? u[pos  1*nx] * invhy2 : 0; // bound check
// x direction, loop tiling
for (int n = 0; n < m; n++) {
// x  1
Lu[n] += u[pos  1 + n*nx] * invhx2;
// x
center = u[pos + n*nx]; // store for reuse
Lu[n] += center * invhxyz2;
// x + 1
Lu[n] += u[pos + 1 + n*nx] * invhx2;
// reuse: y + 1 for prev n
if (n > 0) Lu[n1] += center * invhy2;
// reuse: y  1 for next n
if (n < m  1) Lu[n+1] += center * invhy2;
}
// y + 1
Lu[m1] += j < ny  m ? u[pos + m*nx] * invhy2 : 0; // bound check
// z + 1, loop tiling
for (int n = 0; n < m; n++)
Lu[n] += u[pos + slice + n*nx] * invhz2;
// Store only if thread is inside y boundary
for (int n = 0; n < m; n++)
if (n + j > 0 && n + j < ny  1)
f[pos + n*nx] = Lu[n];
}
template <typename T>
void laplacian(T *d_f, T *d_u, int nx, int ny, int nz, int BLK_X, int BLK_Y, int BLK_Z, T hx, T hy, T hz) {
dim3 block(BLK_X, BLK_Y, BLK_Z);
dim3 grid((nx  1) / block.x + 1, (ny  1) / (block.y * m) + 1, (nz  1) / block.z + 1);
T invhx2 = (T)1./hx/hx;
T invhy2 = (T)1./hy/hy;
T invhz2 = (T)1./hz/hz;
T invhxyz2 = 2. * (invhx2 + invhy2 + invhz2);
laplacian_kernel<<<grid, block>>>(d_f, d_u, nx, ny, nz, invhx2, invhy2, invhz2, invhxyz2);
}
We now go into the details of the computational steps within this kernel. First, we access all z  1
grid points followed by a single y  1
:
// z  1, loop tiling
for (int n = 0; n < m; n++)
Lu[n] += u[pos  slice + n*nx] * invhz2;
// y  1
Lu[0] += j > 0 ? u[pos  1*nx] * invhy2 : 0; // bound check
Note that the conditional operator is introduced so that it computes the y  1
stencil for
the n = 0
grid point only if it does not lie on the y
boundary.
Neither the z  1
nor y  1
elements are reused at the thread level.
Next, the thread computes the x
direction stencils:
// x direction, loop tiling
for (int n = 0; n < m; n++) {
// x  1
Lu[n] += u[pos  1 + n*nx] * invhx2;
// x
center = u[pos + n*nx]; // store for reuse
Lu[n] += center * invhxyz2;
// x + 1
Lu[n] += u[pos + 1 + n*nx] * invhx2;
// reuse: y + 1 for prev n
if (n > 0) Lu[n1] += center * invhy2;
// reuse: y  1 for next n
if (n < m  1) Lu[n+1] += center * invhy2;
}
Again, neither the x  1
nor x + 1
points are reused at the thread level, but the
center element u[pos + n*nx]
could be reused up to two times as in the previous kernel.
Afterwards, we load the final y + 1
point as well as all the z + 1
points:
// y + 1
Lu[m1] += j < ny  m ? u[pos + m*nx] * invhy2 : 0; // bound check
// z + 1, loop tiling
for (int n = 0; n < m; n++)
Lu[n] += u[pos + slice + n*nx] * invhz2;
Another conditional operator is used so that it computes the y + 1
stencil of the
n = m  1
grid point so long as it does not lie on the y
boundary.
Lastly, all threads inside the y
boundary are written back to memory:
// Store only if thread is inside y boundary
for (int n = 0; n < m; n++)
if (n + j > 0 && n + j < ny  1)
f[pos + n*nx] = Lu[n];
Let us now experiment with the same tile factors and see if this reordering makes any difference:
Speedup
% of target


Kernel 1  Baseline
1.00
69.4%
Kernel 2  Loop tiling m=1
1.00
69.4%
Kernel 2  Loop tiling m=2
0.98
68.3%
Kernel 2  Loop tiling m=4
0.94
65.5%
Kernel 2  Loop tiling m=8
0.92
64.0%
Kernel 2  Loop tiling m=16
0.29
20.1%
Kernel 3  Reordered loads m=1
1.20
82.9%
Kernel 3  Reordered loads m=2
1.28
88.9%
Kernel 3  Reordered loads m=4
1.34
93.1%
Kernel 3  Reordered loads m=8
1.37
94.8%
Kernel 3  Reordered loads m=16
0.42
29.4%
Even if m=1
, the reordered access pattern for u
elements already provides a significant
boost in performance. The incremental improvements in speedup for each m
is what we were
expecting to see. Let us examine the rocprof
metrics for this new kernel:
FETCH_SIZE (GB)
Fetch efficiency (%)
L2CacheHit (%)


Theoretical
1.074


Kernel 1  Baseline
2.014
53.3
65.0
Kernel 2  Loop tiling m=1
2.014
53.3
65.0
Kernel 2  Loop tiling m=2
1.848
58.1
60.5
Kernel 2  Loop tiling m=4
1.880
57.1
57.0
Kernel 2  Loop tiling m=8
1.820
59.0
56.0
Kernel 2  Loop tiling m=16
5.637
19.1
40.9
Kernel 3  Reordered loads m=1
1.347
79.7
72.0
Kernel 3  Reordered loads m=2
1.166
92.1
70.6
Kernel 3  Reordered loads m=4
1.107
97.0
68.8
Kernel 3  Reordered loads m=8
1.080
99.4
67.7
Kernel 3  Reordered loads m=16
3.915
27.4
44.5
The FETCH_SIZE
metric decreased significant, bringing us remarkably close to the theoretical limit. The L2CacheHit
rate not only increased
but now exceeds what we were originally getting from the baseline kernel. However, we note that there is a significant drop in the cache
hit rate coupled with a significant increase in the fetch sizes when m=16
. For the chosen problem, kernel 3 with m=8
is our best kernel yet,
achieving almost 95% of the target effective memory bandwidth and over 99% fetch efficiency.
Summary#
With both optimizations combined, the FETCH_SIZE
is reduced by up to 2x.
This suggests that our HIP kernel can load data efficiently for a specific grid size.
To accomplish this, we first reduced the number of loads per store instruction by explicitly evaluating multiple
stencils via loop tiling. However, our initial implementation did not improve performance.
To address this, we reordered the memory access pattern to improve the L2 cache hit ratio.
The question now is whether we are “done” optimizing our initial HIP implementation of the finite difference method for the Laplacian.
We must address a few lingering issues first:
Is there room for further performance improvement? We have already optimized the memory movement between L2 cache and global memory, so we must look at other areas for performance gains e.g., latency hiding.
Why does the performance of
m=16
degrade significantly? This happens with or without the reordering of memory access. Perhaps resolving the underlying issues may help us get closer to the target?How do other architectures and problem sizes impact the choice of tile factors? All of our optimizations thus far are tailored towards a single MI250X GCD on a problem size of
nx,ny,nz = 512, 512, 512
.
The next post in this series will answer some of these remaining open questions.
If you have any questions or comments, please reach out to us on GitHub Discussions
